EH4434
|
FRONT SUSPENSION ASSEMBLY |
1 |
|
|
|
|
? |
ED0195
|
HOUSING |
1 |
|
|
|
|
? |
EH6541
|
CAP, SUSPENSION |
1 |
|
|
|
|
? |
WA0363
|
FLAT WASHER - 3/4" (HARDENED) |
60 |
|
|
|
|
? |
VN9105
|
CAPSCREW - 3/4" - 10NC X 3" - G8 |
36 |
|
|
|
|
? |
WA1282
|
RING, BACKUP (1) |
4 |
|
|
|
|
? |
WA5668
|
SEAL, O-RING (1) |
4 |
|
|
|
|
? |
EH3584
|
RETAINER, UPPER BEARING |
1 |
|
|
|
|
? |
PC0467
|
BEARING, UPPER |
1 |
|
|
|
|
? |
EH6529
|
STOP, PISTON |
1 |
|
|
|
|
? |
VW4451
|
NUT |
1 |
|
|
|
|
? |
VC2629
|
PIN, LOCK |
1 |
|
|
|
|
? |
H2981
|
BALL, STEEL |
2 |
|
|
|
|
? |
EH3581
|
ROD, PISTON |
1 |
|
|
|
|
? |
EH3809
|
RETAINER, LOWER BEARING |
1 |
|
|
|
|
? |
PC0468
|
BEARING, LOWER |
1 |
|
|
|
|
? |
VN9141
|
CAPSCREW - 3/4" - 10NC X 3 3/4" - G9 |
24 |
|
|
|
|
? |
VM0314
|
PLUG, O-RING |
1 |
|
|
|
|
? |
VJ3911
|
OIL, SUSPENSION (5 GAL CONTAINER) |
6 |
|
|
|
|
? |
AK3761
|
ADDITIVE, OIL (5 GAL CONTAINER) |
1 |
|
|
|
|
? |
TH7520
|
CAPSCREW - 1" - 14NF X 1 3/4" (SOCKET HEAD) |
1 |
|
|
|
|
? |
PB2194
|
CHARGING VALVE |
1 |
|
|
|
|
? |
TR9993
|
VALVE CAP |
1 |
|
|
|
|
? |
TD7179
|
VALVE CORE |
1 |
|
|
|
|
? |
TF1144
|
O-RING - HOUSING |
1 |
|
|
|
|
? |
WA0052
|
O-RING - VALVE STEM |
1 |
|
|
|
|
? |
VD5076
|
GASKET, FLAT |
1 |
|
|
|
|
? |
TY8879
|
PLUG, VENT |
1 |
|
|
|
|
? |
TZ8637
|
PLUG, SENSOR |
1 |
|
|
|
|
? |
PC0470
|
SEAL, ROD BUFFER - 15 3/4" (1) |
1 |
|
|
|
|
? |
PC0469
|
SEAL, ROD DOUBLE LIP - 15 3/4" (1) |
1 |
|
|
|
|
? |
PC0471
|
SEAL, WIPER - 15 3/4" (1) |
1 |
|
|
|
|
? |
WB2892
|
PLATE, WARNING |
2 |
|
|
|
|
? |
R1073
|
SCREW, DRIVE - #6 X .19 |
8 |
|
|
|
|
? |
EH6536
|
KEY |
1 |
|
|
|
|
? |
EF5480
|
COVER, PROTECTOR |
1 |
|
|
|
|
? |
C1602
|
CAPSCREW - 3/8" - 16NC X 1" |
2 |
|
|
|
|
? |
DF3042
|
FLAT WASHER - 3/8" |
2 |
|
|
|
|
? |
WA0368
|
FLAT WASHER - 1 1/2" (HARDENED) |
12 |
|
|
|
|
? |
VN9182
|
CAPSCREW - 1 1/2" - 6NC X 6" - G8 |
6 |
|
|
|
|
? |
WA0404
|
NUT - 6NC - G8 |
6 |
|
|
|
|
? |
WA0370
|
FLAT WASHER - 1 3/4" (HARDENED) |
12 |
|
|
|
|
? |
WB0925
|
CAPSCREW - 1 3/4" - 5NC X 14" |
8 |
|
|
|
|
? |
WA0405
|
NUT - 5NC - G8 |
4 |
|
|
|
|
? |
ED7915
|
SPACER |
4 |
|
|
|
|
? |
ED7912
|
RETAINER, PLATE |
1 |
|
|
|
|
? |
TY2149
|
FLAT WASHER, (HARDENED) |
28 |
|
|
|
|
? |
WA4817
|
CAPSCREW - 1 1/4" - 12NF X 5" (12 PT HEAD) |
72 |
|
|
|
|
? |
EJ0302
|
ARM, STEERING - L.H. |
1 |
|
|
|
|
? |
EJ0301
|
ARM, STEERING - R.H. |
1 |
|
|
|
|
? |
TF4079
|
CLAMP |
2 |
|
|
|
|
? |
EF3373
|
BOOT |
1 |
|
|
|
|
? |
EF3374
|
BOOT WIRE |
1 |
|
|
|
|
? |
ED7916
|
KEY, SHEAR |
1 |
|
|
|
|
? |
AK4308
|
NOTE: (1) INCLUDED IN AK4308 SEAL KIT. |
-1 |
|
|
|
|
? |
|
(2) INCLUDED IN EG3807 FRONT SUSPENSION ASSM. |
-1 |
|
|
|
|
? |
|
(QUANTITIES SHOWN ARE ONE SIDE ONLY) |
-1 |
|
|
