REAR SUSPENSION ASSEMBLY (EH9423) | AFE50-AG 830E S/N A30641 ANTELOPE COAL

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

AFE50-AG 830E S/N A30641 ANTELOPE COAL

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	ED0191	PISTON	1
?	PB2194	CHARGING VALVE ASSEMBLY (1)/(2)	1
?	TD7179	CORE, VALVE	1
?	TR9993	CAP, VALVE	1
?	TF1144	O-RING	1
?	WA0052	O-RING	1
?	VD5076	GASKET (1)/(2)	1
?	C1602	CAPSCREW - 3/8" - 16NC X 1"	3
?	WA0720	FLAT WASHER - 3/8"	3
?	VZ4269	GUARD, VALVE	1
?	C0312	LOCKWASHER - 3/8"	2
?	TZ9083	PROTECTOR	1
?	EF8679	LOAD WEIGH VALVE ASSEMBLY (3)	1
?	TZ8627	BODY, VALVE	1
?	TD7179	CORE, VALVE	1
?	EF8677	ADAPTOR, TRANSDUCER	1
?	07000-51009	O-RING	1
?	EF8669	TRANSDUCER, PRESSURE (3)	1
?	EC1015	CHECK VALVE - 2 SPEED/OVER SPEED (3)	1
?	EC1447	BODY, VALVE	1
?	TD7179	CORE, VALVE	1
?	TL3995	O-RING	1
?	PB8570	SWITCH, PRESSURE (3)	1
?	VF4319	SCREW, BLEADER	1
?	TY8879	PLUG, VENT	2
?	WA2892	PLATE, DANGER	2
?	R1073	DRIVE SCREW - #6 X 3/16"	8
?	H2981	BALL, STEEL - 3/4"	2
?	VJ3911	OIL, SUSPENSION - (5 GALLON CAN)	3
?	AK3761	ADDITIVE, OIL - (5 GALLON CAN)	1
?	EC1973	HOUSING	1
?	WA0362	FLAT WASHER - 3/4" (HARDENED)	12
?	VM4571	CAPSCREW - 3/4" - 10NC X 2 1/2"	12
?	ED0183	BEARING - BRONZE	1
?	VN6801	CAPSCREW - 3/4" - 10NC X 3 1/2"	24
?	EH7347	BEARING - BRONZE	1
?	PC0673	RING, BACKUP (2)	1
?	WA0180	O-RING (2)	1
?	PC0653	SEAL, ROD BUFFER - 12.00" (2)	1
?	PC0652	SEAL, ROD DOUBLE LIP - 12.00" (2)	1
?	PC0654	SEAL, ROD WIPER - 12.00" (2)	1
?		NOTE: NS = NOT SHOWN	-1
?	WA3925	DECAL, HYDRAIR (3)	1
?	RK1887	NOTE: (1) INCLUDED IN RK1887 CHARGING VALVE REPAIR KIT.	-1
?	AK4446	(2) INCLUDED IN AK4446 REAR SUSPENSION SEAL KIT.	-1
?		(3) NOT INCLUDED IN ASSEMBLY	-1
