AFE48-V 930E S/N 32816 & 32837 PHELPS-DODGE MORENCI

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	BF3715	NUT, LOCK (1)	1
?	BF1997	FLAT WASHER (1)	1
?	EF3527	PULLEY	1
?	BF1966	BUSHING, PULLEY	1
?	BF1989	RING, RETAINER (1)	1
?	BF1968	BEARING, FRONT	1
?	BF1988	RING, RETAINER (1)	1
?	BF1990	SCREW, PAN HEAD - #8 - 32NC X 3/8" (1)	15
?	BF1970	PLATE, COVER	1
?	BF3712	HOUSING, FRONT	1
?	BF2002	NUT - (SPECIAL)	18
?	BF1969	COVER, CONTROL UNIT	1
?	BF1972	TERMINAL, OUTPUT	1
?	BF1971	CONTROL UNIT	1
?	BF3716	BOLT (+) - 5/16" - 18NC X 3/4"	1
?	BF1995	LOCKWASHER - 5/16" (1)	1
?	BF1996	FLAT WASHER (1)	1
?	BF3717	LOCKWASHER (1)	1
?	BF3718	CAPSCREW - 1/2" - 13NC X 1" (1)	1
?	BF3720	KEY WOODRUFF (1)	1
?	BF1973	SHAFT/CORE/ROTOR ASSEMBLY	1
?	BF1974	ROTOR ASSEMBLY	2
?	BF1975	SHAFT/CORE ASSEMBLY	1
?	BF3713	RING, RETAINING	2
?	BF1992	LOCKWASHER (1)	2
?	BF1991	CAPSCREW - 3/8" - 16NC X 5/8" (1)	2
?	BF3719	CAPSCREW - #10 - 32NF X 1/2" (1)	12
?	BF3721	NUT - #8 - 32NC (1)	9
?	BF1976	SHELL/STATOR/FIELD ASSEMBLY	1
?	BF1977	STATOR, FRONT	1
?	BF1980	STUD	9
?		SHELL (2)	1
?	BF1981	BUSHING, TENSION	1
?	BF1978	COIL	1
?	BF1979	STATOR, REAR	1
?	BF3722	SCREW, PAN HEAD - #6 - 32NF X 3/8" (1)	18
?	BF3723	NUT - #8 (1)	9
?	BF1982	HOUSING, END	1
?	BF1983	BEARING, REAR	1
?	BF3724	SCREW, LOCK - #10 - 32NC X 5/8" (1)	2
?	BF1962	REGULATOR	1
?	BF3714	O-RING	1
?	BF1985	FAN	1
?	BF2003	FLAT WASHER - (HARDENED) (1)	1
?	BF2004	NUT, LOCK - 1/4" - 20NF (1)	1
?	BF1961	GUARD, FAN	1
?	BF3725	SCREW, SOCKET HEAD - #10 - 32NF X 7/8" (1)	3
?	BF1986	NOTE: (1) NOT SERVICED SEPARATELY - SUPPLIED	-1
?		ONLY IN KIT BF1986.	-1
?		(2) NOT SOLD SEPARATELY.	-1

Komatsu AFE48-V 930E S/N 32816 & 32837 PHELPS-DODGE MORENCI parts catalog PDF

BATTERY CHARGING ALTERNATOR (EF2654) (60143) in AFE48-V 930E S/N 32816 & 32837 PHELPS-DODGE MORENCI. Diagram image and parts list.
