BATTERY CHARGING ALTERNATOR (EF2654) | AFE48-F 930E S/N 32674 PIPELINE

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

#	Part Number	Partname	Quantity
1	BF3715	NUT, LOCK (1)	1
2	BF1997	FLATWASHER (1)	1
3	EF3527	PULLEY	1
4	BF1966	BUSHING, PULLEY	1
5	BF1989	RING, RETAINER (1)	1
6	BF1968	BEARING, FRONT	1
7	BF1988	RING, RETAINER (1)	1
8	BF1990	SCREW, PAN HEAD - #8 - 32NC X 3/8" (1)	15
9	BF1970	PLATE, COVER	1
10	BF2002	NUT - (SPECIAL)	18
11	BF1969	COVER, CONTROL UNIT	1
12	BF1972	TERMINAL, OUTPUT	1
13	BF1971	CONTROL UNIT	1
14	BF3716	BOLT (+), 5/16" - 18NC X 3/4"	1
15	BF1995	LOCKWASHER, 5/16" (1)	1
16	BF1996	FLATWASHER (1)	1
17	BF3717	LOCKWASHER (1)	1
18	BF3718	CAPSCREW, 1/2" - 13NC X 1" (1)	1
19	BF3720	KEY WOODRUFF (1)	1
20	BF1973	ASSM, SHAFT/CORE/ROTOR	1
20	BF1974	ASSM, ROTOR	2
20	BF1975	ASSM, SHAFT/CORE	1
20	BF3713	RING, RETAINING	2
21	BF1992	LOCKWASHER (1)	2
22	BF1991	CAPSCREW, 3/8" - 16NC X 5/8" (1)	2
23	BF3719	CAPSCREW, #10 - 32NF X 1/2" (1)	12
24	BF3721	NUT, #8 - 32NC (1)	9
25	BF1976	ASSM, SHELL/STATOR/FIELD	1
25	BF1977	STATOR, FRONT	1
25	BF1980	STUD	9
25		SHELL (2)	1
25	BF1981	BUSHING, TENSION	1
25	BF1978	COIL	1
25	BF1979	STATOR, REAR	1
26	BF3722	SCREW, PAN HEAD - #6 - 32NF X 3/8" (1)	18
27	BF3723	NUT, #8 (1)	9
28	BF1982	HOUSING, END	1
29	BF1983	BEARING, REAR	1
30	BF3724	SCREW, LOCK - #10 - 32NC X 5/8" (1)	2
31	BF1962	REGULATOR	1
32	BF3714	O-RING	1
33	BF1985	FAN	1
34	BF2003	FLATWASHER, (HARDENED) (1)	1
35	BF2004	NUT, LOCK - 1/4" - 20NF (1)	1
36	BF1961	GUARD, FAN	1
37	BF3725	SCREW, SOCKET HEAD - #10 - 32NF X 7/8" (1)	3
NS\|47	BF1986	NOTE: (1) NOT SERVICED SEPERATELY - SUPPLIED	-1
NS\|48		ONLY IN KIT BF1986.	-1
NS\|49		(2) NOT SOLD SEPERATELY.	-1
