PAYLOAD METER III - CAB | AFE50-AN 830E S/N A30652-A30658 DIAVIK

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

#	Part Number	Partname	Quantity	Reference
1	SP8417	FLAT WASHER - 1/4"	4
2	DC3584	LOCKWASHER - 1/4"	4
3	MM0176	NUT - M6 X 1.00	4
4	EG7505	JUNCTION BOX ASSM - PLM III (SEE INDEX)	1	60532
5	WB0983	GRIP, CORD	1
6	VZ2691	LOCKNUT, CONDULET	1
7	EJ4033	HARNESS - PLM III CAB/JBOX	1
8	TC1565	CLAMP	5
9	MM0471	LOCKWASHER - M10	3
10	MM0461	FLAT WASHER - M10	3
11	MM0178	NUT - M10 X 1.50	3
12	WA5460	CLAMP, HEAVY DUTY	1
13		(NOT USED THIS APPLICATION)	-1
14	MM0703	FLAT WASHER - M8	6
15	VN9907	CLAMP	3
16	MM0702	FLAT WASHER - M6	1
17	VN7121	MACHINE SCREW - #10 - 24NC X 1/2"	1
18	EJ4037	PLATE, CONNECTOR HOLE COVER	1
19	PB9829	SCREW, PAN L - M6 X 1.00 X 16	12
20	SM6073	PLATE, CONNECTOR MOUNTING	1
21	SM6066	COVER, PLM III BENT PLATE	1
22	SM6068	PLATE, PLM III MOUNTING	1
23	MM0574	NUT, WELD - M6 X 1.00	2
24	MM0602	CAPSCREW - M8 X 1.25 X 80	4
25	MM0016	CAPSCREW - M8 X 1.25 X 16	2
26	MM0460	FLAT WASHER - M8	2
27		(NOT USED THIS APPLICATIION)	-1
28	WA5641	MACHINE SCREW - #4 - 40NC X 3/8"	4
29	VD7129	LOCKWASHER - #4	1
30	SF0542	MACHINE SCREW - #4 - 40NC X 5/16"	1
31	VN9717	NUT - #4 - 40NC	1
32	SM2117	PLATE, NUT CONNECTOR SHELL	1
33	PB9862	CAP, PROTECTIVE METAL	1
34	EJ3060	PAYLOAD METER III ASSEMBLY	1
35	VC8762	CAPSCREW - 3/8" - 16NC X 1 1/2"	7
36	TR4436	FLAT WASHER - 3/8"	7
37	TC1231	LOCKWASHER - 3/8"	7
38	SM5049	NUT, SPRING - 3/8" - 16NC	4
39		(NOT USED THIS APPLICATION)	-1
40	VZ1368	GRIP, CORD	1
41	EJ4036	ADAPTOR, GRIP CORD	1
42	SM0724	GASKET	1
43	WA5643	MACHINE SCREW	4
44	SM5110	SENSOR, INCLINOMETER	1
45	TC1233	NUT - 3/8" - 16NC	3
46	PB8256	SCREW, LOCK	2
