SPINDLE, HUB & BRAKE ASSEMBLY (EG3935) | AFE50-BE 830E S/N A30706-A30708 DIAVIK

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

AFE50-BE 830E S/N A30706-A30708 DIAVIK

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity	Reference
?	EB1716	HOUSING, FRONT WHEEL	1
?	PB7362	DISC BRAKE ASSEMBLY (SEE INDEX)	3	11765
?	YA0447	SUPPORT, BRAKE	1
?	WA4682	CAPSCREW - 1" - 14NF X 14 1/2"	18
?	WA0364	FLAT WASHER - 1"	30
?	VN7703	NUT - 1" - 14NF	18
?	VM8258	CAPSCREW - 1" - 8NC X 3 3/4"	18
?	PC0003	CUP, BEARING (1)	1
?	PB9997	CONE, BEARING (1)	1
?	EF9318	SPINDLE	1
?	562-22-32290	PIN (1)	2
?	EB1715	SPACER	1
?	PB5756	SEAL ASSEMBLY (1)	1
?	VN9143	CAPSCREW - 1 1/4" - 7NC X 4"	64
?	TY2149	FLAT WASHER (HARDENED)	64
?	TX4848	DISC	1
?	TY1633	STUD - 1" - 14UNS X 7 1/4"	35
?	R2028	PLUG, PIPE	1
?	PC0006	CUP, BEARING (1)	1
?	PC0001	CONE, BEARING (1)	1
?	SD5211	BUSHING, PIPE	1
?	PB7454	GAUGE, SIGHT	1
?	TY2134	RETAINER, BEARING	1
?	TH6916	VALVE, CHECK	1
?	H6881	PLUG, PIPE	1
?	TY2148	FLAT WASHER (HARDENED)	6
?	TY2135	SHIM - .002 (1)	5
?	TY2136	SHIM - .014 (1)	2
?	TY2137	SHIM - .031 (1)	3
?	WA4795	SEAL, O-RING (1)	1
?	C1616	CAPSCREW - 1/2" - 13NC X 2"	8
?	C1540	LOCKWASHER - 1/2"	8
?	EC3702	COVER	1
?	WA0362	FLAT WASHER - 3/4" (2)	4
?	TX0807	ANGLE (2)	1
?	TH7593	FITTING, ELBOW - 90 DEG (2)	1
?	TX0805	TUBE (2)	1
?	VY8331	CLAMP	1
?	DC7524	CAPSCREW - 3/8" - 16NC X 7/8"	1
?	WA0720	FLAT WASHER - 3/8"	1
?	C0312	LOCKWASHER - 3/8"	1
?	C1521	NUT - 3/8" - 16NC	1
?	TF5190	FITTING, TUBE CONNECTOR (2)	1
?	TR6102	SCREW, BLEEDER (3)	2
?	TX0808	BOSS, BLEEDER REMOTE (2)	1
?	AK4126	NOTE: (1) INCLUDED IN AK4126 BEARING & SEAL KIT.	-1
?		(2) USED ON TOP BRAKE HEAD ONLY.	-1
?		(3) INCLUDED WITH FRONT BRAKE ASSEMBLY.	-1
?		(QUANTITIES SHOWN ARE FOR ONE SIDE ONLY.)	-1
