1 |
PC1149
|
PUMP/CONTAINER, LUBE (SEE INDEX) |
1 |
|
41723 |
|
|
2 |
WB2763
|
DECAL |
1 |
|
|
|
|
3 |
MM0032
|
CAPSCREW - M12 X 1.75 X 30 |
6 |
|
|
|
|
4 |
MM0705
|
FLAT WASHER - M12 (HARDENED) |
6 |
|
|
|
|
5 |
EJ1518
|
HOSE |
1 |
|
|
|
|
6 |
CD8419
|
CLAMP, WORM DRIVE |
1 |
|
|
|
|
7 |
TR9441
|
CLAMP - 1 1/4" I.D. |
1 |
|
|
|
|
8 |
MM0642
|
STUD, WELD - M8 X 1.25 X 25 |
1 |
|
|
|
|
9 |
MM0460
|
FLAT WASHER - M8 |
1 |
|
|
|
|
10 |
MM0177
|
NUT - M8 X 1.25 |
1 |
|
|
|
|
11 |
HA3098
|
HOSE - OIL DRAIN TO TANK |
1 |
|
|
|
|
11 |
WB0459
|
FITTING, STRAIGHT ADAPTOR |
1 |
|
|
|
|
11 |
WB0582
|
FITTING, STRAIGHT ADAPTOR (HYD TANK MANIFOLD) |
1 |
|
|
|
|
12 |
HA7286
|
HOSE - OIL PRESSURE INLET |
1 |
|
|
|
|
12 |
WB0457
|
FITTING, STRAIGHT ADAPTOR |
1 |
|
|
|
|
13 |
HA1261
|
HOSE (SEE REF. NO. 7 ON FOLLOWING PAGE) |
1 |
|
|
|
|
14 |
PC0811
|
FILTER, HYDRAULIC (SEE INDEX) |
1 |
|
41606 |
|
|
15 |
WB0268
|
FITTING, ELBOW - 90 DEG |
3 |
|
|
|
|
16 |
EJ0966
|
BRACKET, MOUNTING |
1 |
|
|
|
|
17 |
C1604
|
CAPSCREW - 3/8" - 16NC X 1 1/2" |
4 |
|
|
|
|
18 |
WA4726
|
FLAT WASHER - 3/8" (HARDENED) |
8 |
|
|
|
|
19 |
PC1296
|
SWITCH, PRESSURE |
1 |
|
|
|
|
20 |
EJ2138
|
HARNESS, LUBE |
1 |
|
|
|
|
21 |
TG2562
|
CLAMP - 1/2" I.D. |
2 |
|
|
|
|
22 |
WB0501
|
FITTING, ELBOW - 90 DEG |
1 |
|
|
|
|
23 |
WB0535
|
FITTING, ELBOW - 45 DEG |
1 |
|
|
|
|
24 |
HA5843
|
HOSE |
1 |
|
|
|
|
25 |
C1601
|
CAPSCREW - 3/8" - 16NC X 3/4" |
4 |
|
|
|
|
26 |
F4037
|
FITTING, PIPE |
1 |
|
|
|
|
27 |
SD5214
|
FITTING, PIPE |
1 |
|
|
|
|
28 |
TG9242
|
CONNECTOR |
1 |
|
|
|
|
29 |
E2579
|
NIPPLE |
1 |
|
|
|
|
NS|33 |
|
NOTE: NS = NOT SHOWN |
-1 |
|
|
|
|
NS|34 |
WB0265
|
FITTING, ELBOW - 90 DEG |
1 |
|
|
|
|
NS|35 |
WB0501
|
FITTING - 90 DEG (CENTER PORT - REAR ACCUM) |
1 |
|
|
