1 |
EG4481
|
BOX, BATTERY DISCONNECT (SEE INDEX) |
1 |
|
41409 |
|
|
2 |
ED1455
|
CABLE |
1 |
|
|
|
|
3 |
VL9602
|
CLAMP |
1 |
|
|
|
|
4 |
EC4946
|
CABLE, JUMPER |
2 |
|
|
|
|
5 |
VC7674
|
CLAMP |
4 |
|
|
|
|
6 |
EB0590
|
CABLE |
1 |
|
|
|
|
7 |
EC0118
|
CABLE |
1 |
|
|
|
|
8 |
ED1456
|
CABLE |
1 |
|
|
|
|
9 |
VZ2691
|
LOCKNUT, CONDULET |
2 |
|
|
|
|
10 |
EB6123
|
CABLE - L.H. STARTER - POSITIVE |
1 |
|
|
|
|
11 |
EB3706
|
CABLE - R.H. STARTER - POSITIVE |
1 |
|
|
|
|
12 |
EB1295
|
CABLE - TO 24V ALTERNATOR |
1 |
|
|
|
|
13 |
CH2918
|
CABLE (FROM BATTERY DISCONNECT SWITCH TO 24V |
1 |
|
|
|
|
13 |
|
STANDOFF IN CONTROL CABINET) |
-1 |
|
|
|
|
14 |
TC1231
|
LOCKWASHER - 3/8" |
4 |
|
|
|
|
15 |
TR4436
|
FLAT WASHER - 3/8" |
4 |
|
|
|
|
16 |
TG5720
|
CAPSCREW - 3/8" - 16NC X 1" |
4 |
|
|
|
|
17 |
PB0429
|
INSULATOR, STAND-OFF |
1 |
|
|
|
|
18 |
VG2358
|
CAPSCREW - 3/8" - 16NC X 2 3/4" |
1 |
|
|
|
|
19 |
TL7218
|
CAPSCREW - 3/8" - 16NC X 7/8" |
1 |
|
|
|
|
20 |
C1521
|
NUT - 3/8" - 16NC |
2 |
|
|
|
|
21 |
TV1918
|
CAPSCREW - 1/2" - 13NC X 1 3/4" |
1 |
|
|
|
|
22 |
TR5445
|
LOCKWASHER - 1/2" |
1 |
|
|
|
|
23 |
TR6008
|
FLAT WASHER - 1/2" |
1 |
|
|
|
|
24 |
TR6643
|
NUT - 1/2" - 13NC |
1 |
|
|
|
|
25 |
TZ9880
|
CABLE - L.H. STARTER - NEGATIVE |
1 |
|
|
|
|
26 |
EB0592
|
CABLE - R.H. STARTER - NEGATIVE |
1 |
|
|
|
|
27 |
VZ0639
|
BATTERY |
4 |
|
|
|
|
28 |
EB5298
|
SPACER |
4 |
|
|
|
|
29 |
VD1921
|
CAPSCREW - 1/4" - 20NC X 2 3/4" |
8 |
|
|
|
|
30 |
TR1307
|
FLAT WASHER - 1/4" |
8 |
|
|
|
|
31 |
DC3584
|
LOCKWASHER - 1/4" |
8 |
|
|
|
|
32 |
TD1549
|
NUT - 1/4" - 20NC |
12 |
|
|
|
|
33 |
EB0576
|
CLAMP, BLOCK |
2 |
|
|
|
|
34 |
VN9735
|
NUT, WING - 5/16" |
10 |
|
|
|
|
35 |
SC4174
|
LOCKWASHER - 5/16" |
10 |
|
|
|
|
36 |
TV0177
|
FLAT WASHER - 5/16" |
10 |
|
|
|
|
37 |
EC0432
|
COVER |
1 |
|
|
|
|
38 |
EC1259
|
BOX, BATTERY |
1 |
|
|
|
|
39 |
EB0223
|
CHANNEL |
2 |
|
|
|
|
40 |
TZ0546
|
CABLE |
1 |
|
|
|
|
41 |
VH9969
|
WELD STUD - 3/8" - 16NC X 3/4" |
1 |
|
|
|
|
42 |
DF3042
|
LOCKWASHER - 3/8" |
1 |
|
|
|
|
43 |
TC1233
|
NUT - 3/8" - 16NC |
1 |
|
|
|
|
44 |
EG4490
|
HARNESS |
2 |
|
|
|
|
NS|46 |
|
NOTE: NS = NOT SHOWN |
-1 |
|
|
|
|
NS|47 |
EC4518
|
SHIELD, HEAT |
1 |
|
|
|
|
NS|48 |
TC1234
|
CAPSCREW - 3/8" - 16NC X 3/4" |
8 |
|
|
|
|
NS|49 |
TR4436
|
FLAT WASHER - 3/8" |
8 |
|
|
|
|
NS|50 |
TC1231
|
LOCKWASHER - 3/8" |
8 |
|
|
|
|
NS|51 |
EB0598
|
INSULATION, END (BATTERY BOX) |
2 |
|
|
|
|
NS|52 |
EB0599
|
INSULATION, SIDE (BATTERY BOX) |
1 |
|
|
|
|
NS|53 |
EB0600
|
INSULATION, SIDE (BATTERY BOX) |
1 |
|
|
|
|
NS|54 |
EB0726
|
INSULATION, LID (BATTERY BOX) |
1 |
|
|
