DRIVE AXLE & MOUNTING | AFE50-CZ 830E S/N A30886 I.O.C.C.

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

AFE50-CZ 830E S/N A30886 I.O.C.C.

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	EL0084	AXLE HOUSING ASSEMBLY	1
?	EL3870	AXLE HOUSING	1
?	TX8110	SLEEVE (2)	6
?	VN9106	CAPSCREW - 1 1/4" - 7NC X 3"	24
?	WA0366	FLAT WASHER - 1 1/4" (HARDENED)	124
?	EK1626	PIVOT EYE ASSEMBLY	1
?	ED6114	EYE, PIVOT	1
?	PC1291	BEARING (1)	1
?	EG3026	CARRIER, BEARING (1)	1
?	EG3028	SPACER (1)	2
?	WB1154	CAPSCREW - 3/4" - 10NC X 6" (12 PT) (1)	8
?	VL2993	LOCKNUT - 3/4" - 10NC (1)/(2)	10
?	EG3033	PIN, PIVOT (1)	1
?	VN3270	CAPSCREW - 1 1/4" - 7NC X 5"	96
?	TY1344	RETAINER, BEARING (1)	2
?	EG3027	PLATE, LOCKING (1)	1
?	WB1059	CAPSCREW - 1 1/4" - 7NC X 4 1/2" (12 PT) (1)	4
?	CE2510	CAPSCREW - 5/8" - 11NC X 3/4" (2)	2
?	C1633	CAPSCREW - 5/8" - 11NC X 2 3/4" (1)	3
?	C1541	LOCKWASHER - 5/8" (1)/(2)	4
?	VN9211	CAPSCREW - 3/4" - 10NC X 7 1/2" (2)	2
?	TY2734	SPACER (2)	4
?	EC5272	ANTI-SWAY BAR ASSEMBLY	1
?	EC4617	BAR, ANTI-SWAY	1
?	VN9351	RING, RETAINER (2)	4
?	PB0027	BEARING, SPHERICAL (2)	2
?	EK1326	PIN, BEARING (2)	2
?	AK4952	NOTE: (1) INCLUDED IN AK4952 NOSE CONE PIN KIT.	-1
?	AK7323	(2) INCLUDED IN AK7323 PAN HARD ROD PIN KIT.	-1
