AFE50-CP 830E S/N A30842-A30844 ANTELOPE COAL

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity	Reference
?	PB3347	SHUNT	2
?	PB3348	STAND-OFF, INSULATED	4
?	VC1387	CAPSCREW - 1/2" - 13NC X 1"	4
?	TR6008	FLAT WASHER - 1/2"	8
?	TR5445	LOCKWASHER - 1/2"	4
?	PB5430	STAND-OFF, INSULATED	3
?	C7595	CAPSCREW - 5/8" - 11NC X 1 1/4"	3
?	C1550	FLAT WASHER - 5/8"	3
?	C1541	LOCKWASHER - 5/8"	3
?	EG8413	BUS BAR	1
?	PB3167	TRANSFORMER, RIPPLE	1
?	VE6113	PANEL, FDP (SEE INDEX)	1	64065
?	PB3605	CLAMP	1
?	MM0459	FLAT WASHER - M6	2
?	MM0469	LOCKWASHER - M6	2
?	MM0176	NUT, HEX - M6 X 1.00	2
?	PB3606	SPACER	2
?	VC5344	FLAT WASHER - #10	2
?	DC3101	LOCKWASHER - #10 - 24NC X 3/8"	2
?	F9020	NUT - #10 - 24NC	2
?	PB5230	RESISTOR	1
?	MM0460	FLAT WASHER - M8	8
?	MM0470	LOCKWASHER - M8	8
?	MM0177	NUT, HEX STYLE - M8 X 1.25	8
?	PB7875	RESISTOR	1
?	ED0372	PLATE, NAME - 74E	1
?	TZ7546	PLATE, NAME - S6	1
?	ED0362	PLATE, NAME - 74D	1
?	ED0361	PLATE, NAME - 71G	1
?	TZ7547	PLATE, NAME - S7	1
?	ED0369	PLATE, NAME - 71K	1
?	WA3108	PLATE, DANGER HIGH VOLTAGE	3
?	ED0356	PLATE, NAME - 7GA1	1
?	ED0365	PLATE, NAME - 74A	1
?	EC7463	PLATE, NAME - FDT	1
?	TZ7517	PLATE, NAME - FDP	1
?	ED0375	PLATE, NAME - 74B	1
?	ED0364	PLATE, NAME - 74	1
?	TZ7518	PLATE, NAME - GFDR	1
?	ED0359	PLATE, NAME - 74AA	1
?	ED0363	PLATE, NAME - 7J9	1
?	TZ7519	PLATE, NAME - MFDR	1
?	ED0366	PLATE, NAME - 7J4	1

Komatsu AFE50-CP 830E S/N A30842-A30844 ANTELOPE COAL parts catalog PDF

CONTROL CABINET - FLOOR (41928) in AFE50-CP 830E S/N A30842-A30844 ANTELOPE COAL. Diagram image and parts list.
