LUBE PUMP ASSEMBLY (XA2788) | AFE50-CE 830E S/N A30811-A30814 EPSA

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

AFE50-CE 830E S/N A30811-A30814 EPSA

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	BF5470	SCREW, FLAT HEAD	2
?	BF5471	COUNTERWEIGHT	2
?	BF5473	RING, RETAINER	2
?	BF5474	CRANKROD	1
?	BF5511	RING, RETAINER	2
?	BF5475	CRANK, ECCENTRIC	1
?	BF5476	BEARING, BALL	1
?	BF5477	PIN, OUTLET	1
?		O-RING (1)	1
?	BF5478	TUBE, PLUNGER	1
?	XA2790	SCREW, BUTTON HEAD	2
?	BF5480	BUSHING, WRIST PIN	2
?	BF5481	ANCHOR, WRIST PIN	1
?		WASHER, BACKUP (1)	1
?		SEAL, CUP (1)	1
?	XA2791	ROD, PLUNGER	1
?	BF5483	SPRING	1
?	LA0906	BALL, STEEL	1
?	XA2017	PLUNGER	1
?	XA2792	TUBE, RECIPROCATING	1
?		SEAL, CUP (1)	1
?		O-RING (1)	1
?	BF5486	CYLINDER	1
?	BF5487	CAGE, BALL	1
?	BF3823	BALL, STEEL	1
?		O-RING (1)	1
?	BF5488	SEAT, CHECK	1
?	BF5489	SCREW, SELF-TAPPING	6
?	BF5490	COVER, HOUSING	1
?		GASKET, COVER (1)	1
?	BF5491	GAUGE, PRESSURE	1
?	BF5492	SCREW, SOCKET HEAD	4
?	XA1987	SWITCH, OVERRIDE	1
?	BF5507	SEAL KIT	1
?	XA3020	KNOB, OVERRIDE	1
?	BF5494	VALVE, SOLENOID	1
?	PB9784	CONNECTOR	1
?	XA2018	MANIFOLD	1
?	PC1770	VALVE, PRESSURE REDUCING	1
?	BF5508	SEAL KIT	1
?	PC1769	VALVE, FLOW CONTROL	1
?	BF5509	SEAL KIT	1
?		O-RING (1)	2
?		GASKET (1)	1
?	BF5498	MOTOR, HYDRAULIC (INCLUDES REF. NOS. 40 AND 41)	1
?	XA2147	WASHER	2
?	BF5499	SCREW, SOCKET HEAD	2
?	BF5500	PLUG, PIPE	1
?	BF5501	HOUSING, PUMP	1
?		RING, BACKUP (1)	2
?		O-RING (1)	2
?		O-RING (1)	2
?	BF5502	NUT	2
?	BF5503	BEARING, BRONZE	1
?		O-RING (1)	1
?		WASHER, BACKUP (1)	1
?		O-RING (1)	1
?	XA2793	TUBE, HOUSING	1
?	BF5505	PLUG, SHOVEL	1
?	BF5506	RING, RETAINER	1
?	BF5510	FITTING, ORIFICE	1
?		GASKET (1)	6
?	XA2148	STRAINER, INLET	1
?	BF5513	NOTE: (1) NOT SERVICED SEPARATELY. INCLUDED IN	-1
?		BF5513 SOFT GOODS KIT.	-1
