FRONT SUSPENSION & MOUNTING | AFE50-CE 830E S/N A30811-A30814 EPSA

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

AFE50-CE 830E S/N A30811-A30814 EPSA

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	EJ6895	FRONT SUSPENSION ASSEMBLY - 14"	1
?	WA2892	PLATE, DANGER	2
?	R1073	DRIVE SCREW - #6 X 3/16"	8
?	VM4571	CAPSCREW - 3/4" - 10NC X 2 1/2"	24
?	WA0362	FLAT WASHER - 3/4" (HARDENED)	48
?	EH7326	CAP, SUSPENSION	1
?	TY8879	PLUG, VENT	1
?	TM9278	PROTECTOR	1
?	C1602	CAPSCREW - 3/8" - 16NC X 1"	2
?	C0312	LOCKWASHER - 3/8"	2
?	PB2194	CHARGING VALVE ASSEMBLY (1)/(2)	1
?	TD7179	CORE, VALVE	1
?	TR9993	CAP, VALVE	1
?	TF1144	O-RING	1
?	WA0052	O-RING	1
?	VD5076	GASKET (1)/(2)	1
?	WA0106	O-RING (1)	4
?	WA1281	RING, BACKUP (1)	4
?	VN9105	CAPSCREW - 7/8" - 9NC X 3"	12
?	WA0363	FLAT WASHER - 7/8" (HARDENED)	12
?	EH7327	BEARING, UPPER	1
?	EH6529	STOP, PISTON	1
?	H2981	BALL, STEEL - 3/4"	2
?	VW4451	NUT, WHEEL	1
?	VC2629	PIN	1
?	EJ6897	PISTON	1
?	EF8393	BEARING, LOWER	1
?	VN9140	CAPSCREW - 3/4" - 10NC X 4"	24
?	VM0314	PLUG, O-RING BOSS	1
?	VJ3911	OIL, SUSPENSION - 5 GALLON CAN	5
?	AK3761	ADDITIVE, OIL - 5 GALLON CAN	1
?	TY5376	HOUSING	1
?	PC0626	SEAL, ROD BUFFER - 14" (1)	1
?	PC0625	SEAL, ROD DOUBLE LIP - 14" (1)	1
?	PC0627	SEAL, WIPER - 14" (1)	1
?	TZ0316	PLATE	1
?	TZ8637	PLUG, SENSOR	1
?	EH6536	KEY, SQUARE	1
?	TX9708	KEY, SHEAR	1
?	EL5423	CAPSCREW - 1 1/2" - 6NC X 13"	8
?	EL5421	SPACER	4
?	TY2228	PLATE, RETAINING	1
?	WA4817	CAPSCREW - 1 1/4" - 12NF X 5" (12 PT)	12
?	WA0404	NUT - 1 1/2" - 6NC	10
?	VN9193	CAPSCREW - 1 1/2" - 6NC X 6 1/2"	6
?	WA0368	FLAT WASHER - 1 1/2"	24
?	TY2149	FLAT WASHER - 1" (HARDENED)	12
?		NOTE: NS = NOT SHOWN	-1
?	WA3925	DECAL, HYDRAIR II	1
?	AK4441	NOTE: (1) INCLUDED IN AK4441 SEAL KIT.	-1
?	RK1887	(2) INCLUDED IN RK1887 CHARGING VALVE REPAIR KIT.	-1
?		(QUANTITIES SHOWN ARE FOR ONE SIDE ONLY.)	-1
