BRAKE VALVE SUB-ASSEMBLY - 1 (BF2875) | AFE52-J 930E-3 S/N A30336-A30340 KLEMKE

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

AFE52-J 930E-3 S/N A30336-A30340 KLEMKE

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	VE8070	COLLAR	2
?	BF2596	NUT	2
?	BF2594	PLUNGER	2
?		SEAL, WIPER (1)	2
?	VE8533	SCREW	1
?	BF2595	PACKING	6
?	BF2598	RING, GLYD	2
?	VE9403	SPRING, PLUNGER RETURN (1)/(2)	2
?	BF2597	SEAT, SPRING (2)	2
?	EF5752	SPOOL, REGULATING	2
?		SLEEVE (1)	2
?	VE9401	SPRING, SPOOL (1)/(2)	2
?		PLUNGER (1)	2
?		SEAL (1)	2
?		PACKING (1)	1
?	VE9418	PLUG	1
?	C1546	FLAT WASHER - 1/4"	4
?		CAPSCREW (1)	4
?	VE9421	RETAINER, SLEEVE	1
?	BF2589	BODY - DUAL VALVE	1
?		SEAL (1)	2
?	EF3449	PLUG, ORIFICE - .045	1
?	VE8080	SPRING, REGULATOR (2)	2
?	BF2599	SPRING, REGULATOR (2)	2
?	BF2593	SEAT - STAGING (2)	2
?	BF2592	PACKING	2
?	BF2591	STUD	2
?		RING, BACKUP (1)	2
?		SEAL (1)	2
?		RING, BACKUP (1)	2
?	WA0019	O-RING	2
?		RING, BACKUP (1)	4
?		NOTE: (1) NOT SERVICED SEPARATELY.	-1
?	AK5063	(2) INCLUDED IN AK5063 SPRING KIT.	-1
