ALTERNATOR - ENGINE MOUNT | AFE52-J 930E-3 S/N A30336-A30340 KLEMKE

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

AFE52-J 930E-3 S/N A30336-A30340 KLEMKE

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity	Reference
?	VJ1073	CAPSCREW - 5/8" - 18NF X 2 1/4"	15
?	VE5184	FLAT WASHER - 5/8"	21
?	GE0789	ADAPTER	1
?	VE1887	STRAP, CONNECTION (1)	1
?	VE4342	BRACKET, INSULATED (1)	7
?	VS6837	CABLE ASSEMBLY	2
?	GE1166	STATOR ASSEMBLY (SEE INDEX)	1	64196
?	GE1167	STATOR REWIND KIT (1)	1
?	GE1078	ROTOR ASSEMBLY (SEE INDEX)	1	64214
?	GE0457	STATOR FRAME & CORE ASSEMBLY (1)	1
?	BF0543	CAPSCREW - 5/16" - 18NF X 2 1/2"	2
?	VE4696	LOCKWASHER - 5/16"	2
?	BF0542	PLATE, CLAMP	1
?	VE7272	SEALER	-1
?	BF1483	CABLE ASSEMBLY	3
?	BF2118	CLAMP ASSEMBLY (TWO PIECE)	1
?	VG8030	CAPSCREW - 1/2" - 13NC X 1 1/2"	8
?	VE5185	FLAT WASHER - 1/2"	20
?	VJ2743	PIN, SPRING DOWEL	1
?	GE0328	CABLE ASSEMBLY (SPEED SENSOR)	1
?	GE1080	HOUSING, INLET	1
?	GE1081	HOUSING, OUTLET	1
?	TC1233	NUT - 3/8" - 16NC	2
?	VS7922	CONNECTOR	1
?	VE3916	PUTTY, AIR DRY	-1
?	VE4334	TAPE, GLASS	-1
?	VE4335	TAPE, FIBERGLASS	-1
?	VE3915	VARNISH	-1
?	VE4625	CAPSCREW - 5/16" - 18NC X 1 1/4"	3
?	VE4648	FLAT WASHER - 5/16"	6
?	VE4626	NUT - 5/16" - 18NC	3
?	VE4542	CAPSCREW - 1/2" - 13NC X 1" (1)	28
?	VE5185	FLAT WASHER - 1/2" (1)	28
?	C1629	CAPSCREW - 5/8" - 11NC X 1 3/4"	6
?	GE1082	IMPELLER	1
?	VE4998	CAPSCREW - 1/2" - 13NC X 4 1/2"	12
?	VE4034	BRUSH, CARBON	6
?	GE0141	CAPSCREW - 5/8" - 11NC X 2 1/4"	6
?	VE4631	FLAT WASHER - 5/8"	6
?	GE1079	HEAD, FRAME	1
?	GE0790	LUBRIPLATE	-1
?	GE1172	PLUG, PIPE - 1"	1
?	VE4500	CAPSCREW - 3/8" - 16NC X 1 3/4"	44
?	VE3027	FLAT WASHER - 3/8"	65
?	TC1233	NUT - 3/8" - 16NC	21
?	VJ1028	SUPPORT/STUD	6
?	VJ1024	HOLDER, BRUSH (SEE INDEX)	6	64030
?		NOTE: (1) INCLUDED IN GE1166 STATOR ASSEMBLY.	-1
