AFE52-J 930E-3 S/N A30336-A30340 KLEMKE

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity	Reference
?	EJ7886	HANDRAIL, DIAGONAL LADDER	1
?	MM0012	CAPSCREW - M16 X 2.00 X 25	12
?	MM0706	FLAT WASHER - M16 (HARDENED)	12
?	EJ6619	HANDRAIL, VERTICAL LADDER	2
?	MM0619	CAPSCREW - M12 X 1.75 X 35	7
?	MM0714	FLAT WASHER - M12 (HARDENED)	45
?	MM0472	LOCKWASHER - M12	45
?	MM0179	NUT - M12 X 1.75	7
?	EJ7431	HANDRAIL	1
?	EJ6611	HANDRAIL	1
?	EG9959	MOUNT, L.H. MIRROR	1
?	MM0608	CAPSCREW - M10 X 1.50 X 40	2
?	MM0713	FLAT WASHER - M10 (HARDENED)	2
?	MM0471	LOCKWASHER - M10	2
?	MM0178	NUT - M10 X 1.50	2
?	PC1253	MIRROR ASSEMBLY - L.H.	1
?	XA2123	BACK, MIRROR	1
?	XA2124	CHANNEL, RETAINING	1
?	XA2125	GLASS, MIRROR	1
?	XA2126	CAPSCREW - 1/4" - 20NC X 3/4"	2
?	VN9772	LOCKWASHER - 1/4"	2
?	XA2127	NUT - 1/4" - 20NC	2
?	EG8054	MOUNT, R.H. MIRROR	1
?	EB4395	BRACE	1
?	C1605	CAPSCREW - 3/8" - 16NC X 1 3/4"	2
?	WA4726	FLAT WASHER - 3/8" (HARDENED)	2
?	HE5611	LOCKNUT - 3/8" - 16NC	2
?	PB7490	ARM BOW ASSEMBLY - R.H. (SEE FIG 60560)	1	60560
?	PB7491	CONVEX MIRROR ASSEMBLY - R.H. (SEE FIG 60560)	1	60560
?	TR4731	CAPSCREW - 5/16" - 18NC X 1"	8
?	TV0177	FLAT WASHER - 5/16"	8
?	SC4174	LOCKWASHER - 5/16"	8
?	MM0594	CAPSCREW - M8 X 1.25 X 25	4
?	MM0460	FLAT WASHER - M8	4
?	MM0470	LOCKWASHER - M8	4
?	MM0618	CAPSCREW - M12 X 1.75 X 30	38
?	EJ7877	HANDRAIL	1
?	EJ7880	HANDRAIL	1
?	AK7503	LIGHT, FLOOD (SEE FIG 60111)	1	60111
