AFE57-CB 830E-1AC S/N A30340 - A30343 FELIX RESOURCES

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	EG6540	GASKET	2
?	C1604	CAPSCREW - 3/8" - 16NC X 1 1/2"	8
?	C0312	LOCKWASHER - 3/8"	8
?	ED9901	SEAL, RING	3
?	C5771	PLUG, PIPE - 1/2"	3
?	EL3312	ELBOW	2
?	EH3196	GASKET	1
?	C1606	CAPSCREW - 3/8" - 16NC X 2"	4
?	C1547	FLAT WASHER - 3/8"	4
?	EH2014	ELBOW	1
?	TF6957	DRAIN COCK	1
?	SF9435	PLUG, MAGNETIC	1
?	E2579	NIPPLE	1
?	WB1051	CLAMP, T-BOLT	4
?	EH2017	HOSE	1
?	EG6269	HOSE	1
?	WB1088	CLAMP, T-BOLT	4
?	PB9858	ADAPTER	1
?	VC6039	FITTING, 90 DEGREE ELBOW	1
?	TC1234	CAPSCREW - 3/8" - 16NC X 3/4"	2
?	TC1231	LOCKWASHER - 3/8"	2
?	TR4436	FLAT WASHER - 3/8"	2
?	EL7057	BRACKET	1
?	MM0606	CAPSCREW - M10 X 1.50 X 30	4
?	MM0713	FLAT WASHER - M10	4
?	MM0471	LOCKWASHER - M10	4
?	MM0719	NUT - M10 X 1.50	4
?	EL2027	PLATE, BENT	1
?	EL0668	BRACKET	1

Komatsu AFE57-CB 830E-1AC S/N A30340 - A30343 FELIX RESOURCES parts catalog PDF

COOLING SYSTEM PIPING 3/3 (42722) in AFE57-CB 830E-1AC S/N A30340 - A30343 FELIX RESOURCES. Diagram image and parts list.
