1
WA2892
PLATE, DANGER
2
2
R1073
DRIVE SCREW - #6 X 3/16"
8
3
VM4571
CAPSCREW - 3/4" - 10NC X 2 1/2"
24
4
WA0362
FLAT WASHER - 3/4" (HARDENED)
48
5
EH7326
CAP, SUSPENSION
1
6
TY8879
PLUG, VENT
1
7
TM9278
PROTECTOR
1
8
C1602
CAPSCREW - 3/8" - 16NC X 1"
2
9
C0312
LOCKWASHER - 3/8"
2
10
PB2194
CHARGING VALVE ASSEMBLY (1)/(2)
1
10
TD7179
CORE, VALVE
1
10
TR9993
CAP, VALVE
1
10
TF1144
O-RING
1
10
WA0052
O-RING
1
11
VD5076
GASKET (1)/(2)
1
12
WA0106
O-RING (1)
4
13
WA1281
RING, BACKUP (1)
4
14
VN9105
CAPSCREW - 7/8" - 9NC X 3"
12
15
WA0363
FLAT WASHER - 7/8" (HARDENED)
12
16
EH7327
BEARING, STRUCTURE (UPPER)
1
17
EH6529
STOP, PISTON
1
18
H2981
BALL, STEEL - 3/4"
2
19
VW4451
NUT, WHEEL
1
20
VC2629
PIN
1
21
EJ6897
PISTON
1
22
EF8393
BEARING, STRUCTURE (LOWER)
1
23
VN9140
CAPSCREW - 3/4" - 10NC X 4"
24
24
VM0314
PLUG, O-RING BOSS
1
25
AK4065
OIL, SUSPENSION W/ FRICTION MODIFIER (5 GAL CAN)(LOW TEMP)
-1
25
AK4066
OIL, SUSPENSION W/ FRICTION MODIFIER (55 GAL DRUM)(LOW TEMP)
-1
26
EM0269
HOUSING
1
27
PC0626
SEAL, ROD BUFFER - 14" (1)
1
28
PC0625
SEAL, ROD DOUBLE LIP - 14" (1)
1
29
PC0627
SEAL, WIPER - 14" (1)
1
30
TZ0316
PLATE
1
31
TZ8637
PLUG, SENSOR
1
32
EH6536
KEY, SQUARE
1
NS|38
NOTE: NS = NOT SHOWN
-1
NS|39
WA3925
DECAL, HYDRAIR II
1
NS|40
AK4441
NOTE: (1) INCLUDED IN AK4441 SEAL KIT.
-1
NS|41
RK1887
(2) INCLUDED IN RK1887 CHARGING VALVE REPAIR KIT.
-1
NS|42
(QUANTITIES SHOWN ARE FOR ONE SIDE ONLY.)
-1
