EM0131
FRAME, GRILLE
1
?
EJ4576
GRILLE, TOP
2
?
EL5323
GRILLE, BOTTOM
2
?
C1613
CAPSCREW - 1/2" - 13NC X 1 1/4"
45
?
WA0360
FLAT WASHER - 1/2" (HARDENED)
45
?
C1540
LOCKWASHER - 1/2"
45
?
TY7538
CLIP
22
?
WA3364
SCREW, LOCK
22
?
WB1304
CLAMP, CUSHIONED - 9/16"
15
?
C1547
FLAT WASHER - 3/8"
19
?
MM0471
LOCKWASHER - M10
24
?
MM0178
NUT - M10 X 1.50
23
?
EK9071
DAM, AIR
2
?
VN6450
CAPSCREW - 3/8" - 16NC X 7/8"
19
?
EM5481
COVER, SURGE TANK
1
?
TY7528
PLATE, COVER
1
?
VC7836
FLAT WASHER - 1/2"
2
?
VG7811
LOCKNUT, NYLON - 1/2" - 13NC
1
?
PB6877
NUT, LEVER
1
?
PB6842
HOOK, HOOD (RUBBER)
2
?
C1639
CAPSCREW - 5/16" - 18NC X 2"
2
?
VN9951
LOCKNUT - 5/16" - 18NC
2
?
TY7544
COVER
2
?
WA4513
SCREW, SELF-TAPPING - #10 - 24NC X 1/2"
40
?
AK7525
HEADLIGHT ASSEMBLY, HIGH BEAM (SEE FIG 42268)
4
42268
?
AK7526
HEADLIGHT ASSEMBLY, LOW BEAM (SEE FIG 42268)
4
42268
?
MM0461
FLAT WASHER - M10
24
?
AK7503
FLOOD LIGHT ASSEMBLY (SEE FIG 42185)
1
42185
?
TD0794
CAPSCREW - 5/16" - 18NC X 3/4"
1
?
SC4174
LOCKWASHER - 5/16"
1
?
TY7535
DAM, AIR
1
?
MM0603
CAPSCREW - M10 X 1.50 X 16
1
?
WB1301
CLAMP, CUSHIONED - 1/4"
8
?
EM3816
HOUSING, HEADLIGHT
2
?
EM2965
PLATE, COVER
2
?
TC1231
LOCKWASHER - 3/8"
8
?
TC1234
CAPSCREW - 3/8" - 16NC X 3/4"
8
?
SG2103
GROMMET, RUBBER
2
?
MM0460
FLAT WASHER - M8
8
?
MM0470
LOCKWASHER - M8
8
?
MM0594
CAPSCREW - M8 X 1.25 X 25
8
