AFE57-AT 830E-1AC S/N A30182, A30186-A30187, A30191-A30193 CARDINAL RIVER / NORTH AMERICAN CONSTRUCTION

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity	Reference
?	SM1094	GLASS, REAR	1
?	SM2045	CHANNEL, RUBBER	1
?	VE5837	LIGHT, DOME	1
?	VE8635	LENS, PLASTIC	1
?	VE8636	SWITCH	1
?	VZ1912	BULB	1
?	SM2879	GLASS, FRONT - R.H.	1
?	EM0049	DOOR ASSEMBLY, R.H. (SEE INDEX)	1	41974
?	VN9097	CAPSCREW - 1 X 8NC X 2 3/4"	32
?	TY2148	FLAT WASHER - 1" (HARDENED)	32
?	EL1949	SHIM, FRONT - 1 MM	-1
?	EL1950	SHIM, REAR - 1 MM	-1
?	EL4580	PLATE, CONNECTOR (SEE FIG 60924)	1	60924
?	MM0027	CAPSCREW - M6 X 1.00 X 25	8
?	MM0469	LOCKWASHER - M6	8
?	EL2941	PLATE, FLOOR COVER (R.H. FLOOR)	1
?	MM0595	CAPSCREW - M8 X 1.25 X 30	4
?	MM0470	LOCKWASHER - M8	4
?	SM2189	PLATE, ACCESS - L.H. FLOOR	1
?	SM0991	PLATE, FRONT ACCESS - BRAKE AND STEERING PIPING	1
?	SM0992	PLATE, REAR ACCESS - BRAKE AND STEERING PIPING	1
?	31154R1	CAPSCREW - M8 X 12	14
?	SM2402	SEAL, DOOR	1
?	SM2897	SPACER	-1
?	SM2165	BRACKET, DOOR STRAP	2
?	EL1022	CAPSCREW - BLANK DRILLED	2
?	SM2322	CLIP, HAIR PIN	2
?	SM2582	SEAL, INNER DOOR	2
?	MM0471	LOCKWASHER - M10	20
?	MM0604	CAPSCREW - M10 X 1.50 X 20	20

Komatsu AFE57-AT 830E-1AC S/N A30182, A30186-A30187, A30191-A30193 CARDINAL RIVER / NORTH AMERICAN CONSTRUCTION parts catalog PDF

CAB ASSEMBLY 2/2 (EM0034) (41976) in AFE57-AT 830E-1AC S/N A30182, A30186-A30187, A30191-A30193 CARDINAL RIVER / NORTH AMERICAN CONSTRUCTION. Diagram image and parts list.
