1
EL0307
CABINET
1
2
EK5332
FILTER, NOISE
1
3
PC1345
FUSE BLOCK W/ COVER
4
4
DC3101
LOCKWASHER - #10
16
5
VC5344
FLAT WASHER - #10
16
6
PC2399
FUSE - 1 AMP
1
7
08041-00500
FUSE - 5 AMP
9
8
08041-01000
FUSE - 10 AMP
19
9
08041-01500
FUSE - 15 AMP
15
10
08041-02000
FUSE - 20 AMP
9
11
WB2941
NAME PLATE - FUSE BLOCK #1
1
12
WB2942
NAME PLATE - FUSE BLOCK #2
1
13
EK2512
NAME PLATE - FUSE BLOCK #3
1
14
EK2513
NAME PLATE - FUSE BLOCK #4
1
15
EK2058
BRACKET, MOUNTING - CIRCUIT BREAKER
1
16
ED1549
NUT - 1/4" - 20NC
4
17
DC3584
LOCKWASHER - 1/4"
4
18
TR1307
FLAT WASHER - 1/4"
4
19
PC0254
SWITCH, ROCKER (LOCKED)
1
20
WB2200
NAME PLATE - DLS
1
21
EK2075
NAME PLATE - FS1 - FS12 CIR 712
1
22
EL7627
NAME PLATE - FS13 - FS16 12V REG
1
23
EK2502
NAME PLATE - FS17 - FS24 CIR 11S
1
24
EK2503
NAME PLATE - FS1 - FS12 CIR 11
1
25
EK2501
NAME PLATE - FS13 - FS16
1
26
EL7626
NAME PLATE - FS17 - FS24 CIR 11B1
1
27
EK2505
NAME PLATE - FS1 - FS12 CIR 71
1
28
EK2508
NAME PLATE - FS13 - FS16 CIR 15SPD
1
29
EK2509
NAME PLATE - FS17 - FS24 CIR 12V
1
30
EK2510
NAME PLATE - FS1 - FS12 CIR 71CK
1
31
EK2511
NAME PLATE - FS17 - FS24 CIR 15VD1
1
32
EM1463
HARNESS, AUXILIARY CONTROL CABINET INTERNAL
1
32
EF6927
RESISTOR (22,100 OHM)
1
33
VS0035
LIGHT, DOME
5
33
VZ1912
BULB
5
33
TM9090
INSULATOR
5
34
SF9896
KNIFE, DISCONNECT - 14-16 AWG
5
35
TF6248
FLAT WASHER - #8
15
36
VM9910
LOCKWASHER - #8
15
37
TV2179
NUT - #8 - 32NC
60
38
EC7462
NAME PLATE - DL1
1
39
EC7458
NAME PLATE - DL2
1
40
EC7459
NAME PLATE - DL3
1
41
EC7460
NAME PLATE - DL4
1
42
EC7457
NAME PLATE - DL5
1
43
EM2720
PLATE, BOTTOM
1
44
EL0316
GASKET
1
45
TC1234
CAPSCREW - 3/8" - 16NC X 3/4"
9
46
TC1231
LOCKWASHER - 3/8"
9
47
TR4436
FLAT WASHER - 3/8"
9
48
PC1701
FITTING, BULKHEAD (COAX)
1
49
PC1962
HARNESS, ORBCOMM (COAX)
1
50
CH4074
CABLE, BLACK
1
51
CH3888
CABLE, RED
1
52
EM5634
HARNESS, WHEEL SPEED
1
53
EM4325
HARNESS, AUXILIARY BOX - DASH
1
54
EL5808
HARNESS, CAB/AUXILIARY BOX DIAGNOSTIC
1
55
EM0296
HARNESS, AUXILIARY BOX - OVERHEAD
1
56
EL8050
HARNESS, COMPONENTS P240
1
57
EM0297
HARNESS, AUXILIARY - CAB, GE
1
58
EM4318
HARNESS, ENGINE
1
59
EM2964
HARNESS, AUXILIARY BOX - ENGINE
1
60
SD5390
MACHINE SCREW - #10 - 32NF X 1"
1
61
VZ1369
LOCKNUT, CONDULET
2
62
WB3313
NAME PLATE - FS13 - FS16, CIR II GL
1
63
WA0724
PLUG - 2"
1
64
TV3555
PLUG, BUTTON - 1 3/8" DIAMETER
2
NS|68
NOTE: NS = NOT SHOWN
-1
NS|69
EM2757
LABEL, FUSE BLOCK (INSIDE CABINET DOOR)
1
