1 |
EL0307
|
CABINET |
1 |
|
|
|
|
2 |
EK5332
|
FILTER, NOISE |
1 |
|
|
|
|
3 |
PC1345
|
FUSE BLOCK W/ COVER |
4 |
|
|
|
|
4 |
DC3101
|
LOCKWASHER - #10 - 24NC X 3/8" |
16 |
|
|
|
|
5 |
VC5344
|
FLAT WASHER - #10 |
16 |
|
|
|
|
6 |
PC2399
|
FUSE - 1 AMP |
1 |
|
|
|
|
7 |
08041-00500
|
FUSE - 5 AMP |
11 |
|
|
|
|
8 |
08041-01000
|
FUSE - 10 AMP |
21 |
|
|
|
|
9 |
08041-01500
|
FUSE - 15 AMP |
12 |
|
|
|
|
10 |
08041-02000
|
FUSE - 20 AMP |
9 |
|
|
|
|
11 |
WB2941
|
NAME PLATE - FUSE BLOCK #1 |
1 |
|
|
|
|
12 |
WB2942
|
NAME PLATE - FUSE BLOCK #2 |
1 |
|
|
|
|
13 |
EK2512
|
NAME PLATE - FUSE BLOCK #3 |
1 |
|
|
|
|
14 |
EK2513
|
NAME PLATE - FUSE BLOCK #4 |
1 |
|
|
|
|
15 |
EK2058
|
BRACKET, MOUNTING - CIRCUIT BREAKER |
1 |
|
|
|
|
16 |
ED1549
|
NUT - 1/4" - 20NC |
4 |
|
|
|
|
17 |
DC3584
|
LOCKWASHER - 1/4" |
4 |
|
|
|
|
18 |
TR1307
|
FLAT WASHER - 1/4" |
4 |
|
|
|
|
19 |
PC0254
|
SWITCH, ROCKER (LOCKED) |
1 |
|
|
|
|
20 |
WB2200
|
NAME PLATE - DLS |
1 |
|
|
|
|
21 |
EK2075
|
NAME PLATE - FS1 - FS12 CIR 712 |
1 |
|
|
|
|
22 |
EL7627
|
NAME PLATE - FS13 - FS16 12V REG |
1 |
|
|
|
|
23 |
EK2502
|
NAME PLATE - FS17 - FS24 CIR 11S |
1 |
|
|
|
|
24 |
EK2503
|
NAME PLATE - FS1 - FS12 CIR 11 |
1 |
|
|
|
|
25 |
EK2501
|
NAME PLATE - FS13 - FS16 |
2 |
|
|
|
|
26 |
EL7626
|
NAME PLATE - FS17 - FS24 CIR 11B1 |
1 |
|
|
|
|
27 |
EK2505
|
NAME PLATE - FS1 - FS12 CIR 71 |
1 |
|
|
|
|
28 |
EK2508
|
NAME PLATE - FS13 - FS16 CIR 15SPD |
1 |
|
|
|
|
29 |
EK2509
|
NAME PLATE - FS17 - FS24 CIR 12V |
1 |
|
|
|
|
30 |
EK2510
|
NAME PLATE - FS1 - FS12 CIR 71CK |
1 |
|
|
|
|
31 |
EK2511
|
NAME PLATE - FS17 - FS24 CIR 15VD1 |
1 |
|
|
|
|
32 |
EL8043
|
HARNESS, AUXILIARY CONTROL CABINET INTERNAL |
1 |
|
|
|
|
33 |
VS0035
|
LIGHT, DOME |
5 |
|
|
|
|
33 |
VZ1912
|
BULB |
5 |
|
|
|
|
33 |
TM9090
|
INSULATOR |
5 |
|
|
|
|
34 |
SF9896
|
KNIFE, DISCONNECT - 14-16 AWG |
5 |
|
|
|
|
35 |
TF6248
|
FLAT WASHER - #8 |
15 |
|
|
|
|
36 |
VM9910
|
LOCKWASHER - #8 |
15 |
|
|
|
|
37 |
TV2179
|
NUT - #8 - 32NC |
60 |
|
|
|
|
38 |
EC7462
|
NAME PLATE - DL1 |
1 |
|
|
|
|
39 |
EC7458
|
NAME PLATE - DL2 |
1 |
|
|
|
|
40 |
EC7459
|
NAME PLATE - DL3 |
1 |
|
|
|
|
41 |
EC7460
|
NAME PLATE - DL4 |
1 |
|
|
|
|
42 |
EC7457
|
NAME PLATE - DL5 |
1 |
|
|
|
|
43 |
EL0315
|
PLATE, BOTTOM |
1 |
|
|
|
|
44 |
EL0316
|
GASKET |
1 |
|
|
|
|
45 |
TC1234
|
CAPSCREW - 3/8" - 16NC X 3/4" |
9 |
|
|
|
|
46 |
TC1231
|
LOCKWASHER - 3/8" |
9 |
|
|
|
|
47 |
TR4436
|
FLAT WASHER - 3/8" |
9 |
|
|
|
|
48 |
PC1701
|
FITTING, BULKHEAD (COAX) |
1 |
|
|
|
|
49 |
PC1962
|
HARNESS, ORBCOMM (COAX) |
1 |
|
|
|
|
50 |
CH4074
|
CABLE, BLACK |
1 |
|
|
|
|
51 |
CH3888
|
CABLE, RED |
1 |
|
|
|
|
52 |
EL5810
|
HARNESS, WHEEL SPEED |
1 |
|
|
|
|
53 |
EL5811
|
HARNESS, AUXILIARY BOX - DASH |
1 |
|
|
|
|
54 |
EL5808
|
HARNESS, CAB/AUXILIARY BOX DIAGNOSTIC |
1 |
|
|
|
|
55 |
EL5812
|
HARNESS, AUXILIARY BOX - OVERHEAD |
1 |
|
|
|
|
56 |
EL5806
|
HARNESS, COMPONENTS P240 |
1 |
|
|
|
|
57 |
EL8046
|
HARNESS, AUXILIARY - CAB, GE |
1 |
|
|
|
|
58 |
EL5807
|
HARNESS, QSK |
1 |
|
|
|
|
59 |
EL5805
|
HARNESS, AUXILIARY BOX - ENGINE |
1 |
|
|
|
|
60 |
SD5390
|
MACHINE SCREW - #10 - 32NC X 1" |
1 |
|
|
|
|
61 |
VZ1369
|
LOCKNUT, CONDULET |
2 |
|
|
|
|
NS|64 |
|
NOTE: NS = NOT SHOWN |
-1 |
|
|
|
|
NS|65 |
EM2757
|
LABEL, FUSE BLOCK (INSIDE CABINET DOOR) |
1 |
|
|
