AFE57-CV 830E-1AC S/N A30461 - A30463 & A30470 - A30472 BARRICK BALD MOUNTAIN

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	EJ9909	CLAMP	4
?	EK1648	ROD, THREADED	4
?	WA0471	CAPSCREW - 1/2" - 13NC X 2 1/4"	10
?	TL8151	JAM NUT - 1/2" X 13NC	10
?	PC1247	ROD END, FEMALE	10
?	DF3500	LOCKNUT - 1/2" - 13NC	10
?	WA4728	FLAT WASHER - 1/2"	20
?	EK1645	ANGLE	2
?	EK1649	ROD, THREADED	1
?	VC8762	CAPSCREW - 3/8" - 16NC X 1 1/2"	3
?	HE5611	LOCKNUT - 3/8" - 16NC	3
?	WA4726	FLAT WASHER - 3/8"	9
?	MM0047	CAPSCREW - M10 X 1.50 X 30	1
?	MM0471	LOCKWASHER - M10	1
?	EG7576	CLAMP, DOUBLE	2
?	MM0004	CAPSCREW - M12 X 1.75 X 20	8
?	MM0714	FLAT WASHER - M12	8
?	WB1179	CLAMP, T-BOLT	8
?	VW7882	HOSE, HUMP	2
?	WB1177	CLAMP, T-BOLT	8
?	EK1646	ANGLE	1
?	WB1170	CLAMP, T-BOLT	8
?	PB2484	ELBOW - 45 DEG	4
?	WB1169	CLAMP, T-BOLT	4

Komatsu AFE57-CV 830E-1AC S/N A30461 - A30463 & A30470 - A30472 BARRICK BALD MOUNTAIN parts catalog PDF

AIR CLEANER PIPING & INSTALLATION ( 2/2) (42130) in AFE57-CV 830E-1AC S/N A30461 - A30463 & A30470 - A30472 BARRICK BALD MOUNTAIN. Diagram image and parts list.
