AFE57-HT 830E-1AC S/N A40966, A40987 & A40990 - A40992 SEVERSTAL

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	VE4641	CAPSCREW - 3/8" - 16NC X 1 1/4"	8
?	VE4687	LOCKWASHER - 3/8"	8
?	VJ7941	SUPPORT	4
?	AK7746	BRUSH, CARBON (1)	8
?	XA4559	ARMATURE	1
?	VE4818	PUNCHING, MAIN	256
?	VE4819	PUNCHING, END	4
?	BF1000	SPACER	1
?	BF0999	COMMUTATOR	1
?	58D-98-02110	WEIGHT, BALANCE	-1
?	GE0052	CAP, BRUSH HOLDER	1
?	GE0047	GROUND, BRUSH RING	1
?	VE4409	BRUSH (1)	1
?	VS9059	COLLAR	1
?	VS9032	FLINGER	1
?	VS9262	BEARING, BALL (1)	1
?	VJ6359	HOUSING, BEARING	1
?	VE5884	SCREW	2
?	VE6847	CAP, BEARING	1
?	VS8884	NUT	1
?	VS9031	LOCKWASHER	1
?	TR4731	CAPSCREW - 5/16" - 18NC X 1"	8
?	VE4696	LOCKWASHER - 5/16"	8
?	VJ7666	PLATE	1
?	58D-98-02120	CAPSCREW - #10 - 32 X 5/8"	2
?	58F-GB-AK010	NOTE: (1) INCLUDED IN 58F-GB-AK010 BLOWER MOTOR REBUILD KIT.	-1

Komatsu AFE57-HT 830E-1AC S/N A40966, A40987 & A40990 - A40992 SEVERSTAL parts catalog PDF

RETARDING GRID BLOWER MOTOR 2/5 XA4558 (42860) in AFE57-HT 830E-1AC S/N A40966, A40987 & A40990 - A40992 SEVERSTAL. Diagram image and parts list.
