AFE57-HM 830E-1AC S/N A40953 UNITED TACONITE

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity	Reference
?	GE0861	GROMMET	4
?	BF3904	SHIELD, INSULATION	1
?	BF4223	BOLT, INSULATED	1
?	VE4515	FLAT WASHER - 3/8"	-1
?	VE4687	LOCKWASHER - 3/8"	-1
?	VE4700	NUT - 3/8" - 16NC	-1
?	GE1843	CONTACTOR ASSEMBLY, RP (SEE INDEX)	2	64401
?	GE0219	SUPPORT, MODULE	1
?	GE1416	GROMMET	6
?	GE1397	BUS BAR	1
?	VE4640	CAPSCREW - 3/8" - 16NC X 1 1/2"	-1
?	PB6137	CONTACTOR	1
?	XA4149	INTERLOCK, POSITION SENSOR	1
?	VE1317	CONTACTOR - GF & GFR (SEE INDEX)	1	64069
?	GE0857	PANEL	2
?	VE4902	NUT - 1/4" - 20NC	-1
?	XA5003	LOCKWASHER - 1/4"	-1
?	XA4233	FLAT WASHER - 1/4"	-1
?	GE0032	BUS BAR	3
?	PB3348	INSULATOR	4
?	XA3143	STUD	4
?	VE4519	FLAT WASHER - 1/2"	-1
?	VE4699	LOCKWASHER - 1/2"	-1
?	VE4698	NUT - 1/2" - 13NC	-1
?	GE0220	SUPPORT, MODULE	1
?	VE4655	FLAT WASHER - #10	-1
?	VE3030	FLAT WASHER - 1/2"	-1
?	BF4452	MODULE, SUPPRESSION	1

Komatsu AFE57-HM 830E-1AC S/N A40953 UNITED TACONITE parts catalog PDF

CONTROL CABINET - CONTACTOR BOX 2/2 58E-43-00021 (43449) in AFE57-HM 830E-1AC S/N A40953 UNITED TACONITE. Diagram image and parts list.
