BRAKE VALVE SUB-ASSEMBLY 2/2 BF1851 | AFE57-FW 830E-1AC S/N A30761 WABUSH

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

AFE57-FW 830E-1AC S/N A30761 WABUSH

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	VE8070	COLLAR	2
?	VE8071	PLUNGER	2
?		SEAL (1)	2
?		SPRING, PLUNGER (1)	2
?		SPRING, REGULATOR (1)	2
?		SPRING, REGULATOR (1)	2
?	VE8532	SEAT, SPRING	2
?		SPOOL (3)	2
?		RING, BACKUP (2)	2
?		SEAL (2)	2
?		RING, BACKUP (2)	2
?		SEAL (2)	2
?		SEAL (2)	2
?		SLEEVE (3)	2
?		SPRING, SPOOL (1)	2
?		PLUNGER, REACTION (3)	1
?		PLUNGER, REACTION (3)	1
?		SEAL, WIPER (2)	2
?		RING, BACKUP (2)	2
?	VE8086	SEAL (2)	2
?		BODY (4)	1
?		SEAL (2)	1
?		SEAL (2)	1
?	VE8533	SCREW	1
?		SEAL (2)	1
?	VE9418	PLUG	1
?	VE9421	SLEEVE, RETAINER	1
?	C1546	FLAT WASHER - 1/4"	4
?		SCREW (4)	4
?		PLATE (4)	1
?		CAPSCREW (4)	4
?	BF1860	NOTE: (1) INCLUDED IN BF1860 SPRING KIT.	-1
?	BF1861	(2) INCLUDED IN BF1861 SEAL KIT.	-1
?	BF1859	(3) INCLUDED IN BF1859 SPOOL/SLEEVE KIT.	-1
?		(4) NOT SERVICED SEPARATELY.	-1
