ALTERNATOR - ENGINE MOUNT ( 1/2) | AFE59-BR 930E-4 S/N A30742 FORDING

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

AFE59-BR 930E-4 S/N A30742 FORDING

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity	Reference
?	XA4401	ADAPTER	1
?	VJ1073	CAPSCREW - 5/8" - 18NF X 2 1/4"	15
?	VE5184	FLAT WASHER - 5/8"	21
?	GE1167	STATOR REWIND KIT (1)	1
?	VE1887	STRAP, CONNECTION (1)	1
?	VE4342	BRACKET, INSULATED (1)	7
?	XA3159	STATOR ASSEMBLY (SEE INDEX)	1	64196
?	XA4402	ROTOR ASSEMBLY (SEE INDEX)	1	64214
?	VJ2743	ROLLPIN	1
?	XA3160	STATOR FRAME & CORE ASSEMBLY (1)	1
?	VE2753	BRACKET	7
?	VE4542	CAPSCREW - 1/2" - 13NC X 1" (1)	28
?	VE5185	FLAT WASHER - 1/2" (1)	28
?	GE0328	CABLE ASSEMBLY (SPEED SENSOR)	1
?	GE1080	HOUSING, INLET	1
?	VE4500	CAPSCREW - 3/8" - 16NC X 1 3/4"	44
?	VE3027	FLAT WASHER - 3/8"	65
?	TC1233	NUT - 3/8" - 16NC	21
?	GE1081	HOUSING, OUTLET	1
?	C1629	CAPSCREW - 5/8" - 11NC X 1 3/4"	6
?	VE4998	CAPSCREW - 1/2" - 13NC X 4 1/2"	12
?	VE5185	FLAT WASHER - 1/2"	20
?	GE1082	IMPELLER	1
?	GE0141	CAPSCREW - 5/8" - 11NC X 2 1/4"	6
?	VE4631	FLAT WASHER - 5/8"	6
?	GE1172	PLUG, PIPE - 1"	1
?	VJ9656	LIQUID GASKET	-1
?	GE1079	HEAD, FRAME	1
?	GE0790	LUBRIPLATE	-1
?	VG8030	CAPSCREW - 1/2" - 13NC X 1 1/2"	8
?	VE8444	BRUSH, CARBON	6
?	VJ1024	HOLDER, BRUSH (SEE INDEX)	6	64030
?	XA3890	SEAL, V-RING	1
?		NOTE: (1) INCLUDED IN XA3159 STATOR ASSEMBLY.	-1
?		(SEE FOLLOWING PAGES FOR DETAIL A AND VIEW B-B.)	-1
