AFE59-BR 930E-4 S/N A30742 FORDING

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	EM1400	HOUSING, AXLE	1
?	WA0366	FLAT WASHER - 1 1/4" (HARDENED)	28
?	WB1162	CAPSCREW - 1 1/4" - 7NC X 3"	28
?	EL4784	PIVOT EYE ASSEMBLY	1
?	EL4783	EYE, PIVOT	1
?	PC1291	BEARING (1)	1
?	EH7812	SWAY BAR W/ BEARINGS	1
?	EH7813	BAR, ANTI-SWAY	1
?	PB0027	BUSHING, BALL (2)	2
?	VN9351	RING, RETAINING (2)	4
?	EJ9707	HOSE, DRIVE AXLE BLOWER	1
?	EL0047	RETAINER, BEARING (1)	2
?	EG3028	SPACER (1)	2
?	EK0867	PIN, PIVOT (1)	1
?	ED4952	SLEEVE (1)	1
?	WB1154	CAPSCREW - 3/4" - 10NC X 6" (1)	14
?	VL2993	LOCKNUT - 3/4" - 10NC (1)	14
?	EK0866	PLATE, LOCKING (1)	1
?	VN5153	WIRE, GROUND	1
?	WB1059	CAPSCREW - 1 1/4" - 7NC X 4 1/2" (12 PT) (1)	5
?	C1541	LOCKWASHER - 5/8" (1)	3
?	VN9087	CAPSCREW - 5/8" - 11NC X 2 1/2" (1)	3
?	EH7811	PIN, BEARING (2)	2
?	MM0173	CAPSCREW - M20 X 2.50 X 200 (2)	2
?	MM0697	LOCKNUT - M20 X 2.50 (2)	2
?	TY2734	SPACER (2)	4
?	MM0474	LOCKWASHER - M16	2
?	MM0012	CAPSCREW - M16 X 2.00 X 25	2
?	TX8110	SLEEVE (2)	2
?	WB1202	CLAMP, T-BOLT	4
?	EJ9711	BRACKET, SUPPORT	1
?	EJ9703	STRAP, SUPPORT	1
?	MM0607	CAPSCREW - M10 X 1.50 X 35	8
?	MM0461	FLAT WASHER - M10	16
?	MM0471	LOCKWASHER - M10	8
?	MM0178	NUT - M10 X 1.50	8
?	VH9969	WELD STUD - 3/8" - 16NC X 3/4"	2
?	C0312	LOCKWASHER - 3/8"	2
?	C1521	NUT - 3/8" - 16NC	2
?	AK5000	NOTE: (1) INCLUDED IN AK5000 DRIVE PIN KIT.	-1
?	AK4321	(2) INCLUDED IN AK4321 PANHARD ROD PIN KIT.	-1
