AFE59-BM 930E-4 S/N A30712 - A30714 CODELCO

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	MM0178	NUT - M10 X 1.50	-1
?	MM0461	FLAT WASHER - M10	-1
?	TF6924	CLAMP, VINYL - 1 3/4" I.D.	-1
?	TC6058	CLAMP, VINYL - 1 1/2" I.D.	-1
?	TY8375	SPACER	5
?	EK9883	SPACER	4
?	WB3097	CLAMP, CUSHIONED - 1/2"	-1
?	WB3096	CLAMP, CUSHIONED - 1 1/4"	-1
?	WB3092	CLAMP, CUSHIONED - 7/8"	-1
?	VL9602	CLAMP, VINYL - 2" I.D.	1
?	MM0042	CAPSCREW - M10 X 1.50 X 25	2
?	EL7728	PLATE	1
?	MM0605	CAPSCREW - M10 X 1.50 X 25	6
?	EL3776	GASKET	1
?	EL3774	COVER	1
?	WB3093	CLAMP, CUSHIONED - 1"	-1
?	MM0604	CAPSCREW - M10 X 1.50 X 20	-1
?	MM0471	LOCKWASHER - M10	-1
?	MM0713	FLAT WASHER - M10 (HARDENED)	-1
?	WB1301	CLAMP, CUSHIONED - 1/4"	-1

Komatsu AFE59-BM 930E-4 S/N A30712 - A30714 CODELCO parts catalog PDF

POWER CABLE ROUTING (REAR VIEW) ( 1/2) (61139) in AFE59-BM 930E-4 S/N A30712 - A30714 CODELCO. Diagram image and parts list.
