AFE59-BM 930E-4 S/N A30712 - A30714 CODELCO

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	VC1390	LOCKWASHER - 5/8"	16
?	C1630	CAPSCREW - 5/8" - 11NC X 2"	16
?	VE4818	PUNCHING, MAIN (1)	256
?	VE4819	PUNCHING, END (1)	4
?	VE7206	TAPE, GLASS - .014 (1)	-1
?	VE2761	ARMATURE REWIND KIT (1)	1
?	VE3915	VARNISH (1 GALLON) (1)	-1
?	BF1001	PUTTY, PERMAFIL (1)	-1
?	VE4687	LOCKWASHER - 3/8"	8
?	VE4641	CAPSCREW - 3/8" - 16NC X 1 1/4"	8
?	VE8978	SEAL, V-RING	1
?	VE4257	FAN	1
?	BF1885	HEAD, FRAME	1
?	VJ9656	LIQUID GASKET - 8 OZ.	-1
?	VS9031	LOCKWASHER - 1 23/32" I.D.	1
?	VE4696	LOCKWASHER - 5/16"	6
?	TR4731	CAPSCREW - 5/16" - 18NC X 1"	6
?	VS8884	NUT - 1 11/16"	1
?	BF1889	COTTER PIN	1
?	VS9062	NUT - 1 1/8"	1
?	BF0997	SHAFT (1)	1
?	VS9221	CAP, BEARING	1
?	VS9262	BEARING, BALL	1
?	VS9032	FLINGER	1
?	VS9061	WEIGHT, BALANCE (1)	-1
?	BF0998	HEAD, ARMATURE (1)	1
?	GE0046	ARMATURE ASSEMBLY	1
?		NOTE: (1) INCLUDED IN GE0046 ARMATURE ASSEMBLY.	-1

Komatsu AFE59-BM 930E-4 S/N A30712 - A30714 CODELCO parts catalog PDF

BLOWER MOTOR (COMMUTATOR END) (XA4146) (64001) in AFE59-BM 930E-4 S/N A30712 - A30714 CODELCO. Diagram image and parts list.
