1 |
EM4514
|
FLANGE HOUSING ASSEMBLY W/ BALLAST (1)/(2)/(3) |
1 |
|
|
|
|
1 |
AK7551
|
FLANGE HOUSING ASSEMBLY (4)/(5) |
1 |
|
|
|
|
2 |
EM4515
|
LIGHT BULB - 24V/35W (1)/(2)/(3) |
1 |
|
|
|
|
3 |
|
(NOT USED IN THIS APPLICATION) |
1 |
|
|
|
|
4 |
AK7554
|
SPRING, BULB RETAINER (MULTIPAK 10) (1)/(2)/(3) |
1 |
|
|
|
|
5 |
EM4511
|
LENS/REFLECTOR - HIGH BEAM (WITHOUT BULB) (1) |
1 |
|
|
|
|
6 |
EM4512
|
LENS/REFLECTOR - LOW BEAM (WITHOUT BULB) (2) |
1 |
|
|
|
|
7 |
EM4513
|
LENS/REFLECTOR - FOG - AMBER (WITHOUT BULB) (3) |
1 |
|
|
|
|
8 |
AK4701
|
LENS/REFLECTOR - RETARD/TURN SIGNAL - AMBER (4) |
1 |
|
|
|
|
9 |
AK4697
|
LENS/REFLECTOR - CLEARANCE - RED (5) |
1 |
|
|
|
|
10 |
AK7556
|
GASKET (MULTIPAK 10) |
1 |
|
|
|
|
11 |
AK7559
|
BEZEL |
1 |
|
|
|
|
12 |
AK7561
|
SCREW |
3 |
|
|
|
|
NS|14 |
|
NOTE: (1) INCLUDED IN EM3267 HEADLIGHT ASSM.(HIGH BEAM) |
-1 |
|
|
|
|
NS|15 |
|
(2) INCLUDED IN EM3268 HEADLIGHT ASSM.(LOW BEAM) |
-1 |
|
|
|
|
NS|16 |
|
(3) INCLUDED IN EM3269 FOG LIGHT ASSEMBLY. |
-1 |
|
|
|
|
NS|17 |
|
(4) INCLUDED IN PC1867 TURN SIGNAL LIGHT ASSM. |
-1 |
|
|
|
|
NS|18 |
|
(5) INCLUDED IN PC1866 CLEARANCE LIGHT ASSM. |
-1 |
|
|
|
|
NS|19 |
|
(ALL PARTS ARE COMMON, EXCEPT WHERE INDICATED.) |
-1 |
|
|
