AFE59-FK 930E-4 S/N A31674 - A31676, A31685, A31687 & A31689 JWANENG

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity	Reference
?	XA4126	LUBE PUMP ASSEMBLY (SEE INDEX)	1	43315
?	BF5439	CAPSCREW	5
?	LA1212	LOCKWASHER	5
?	BF5440	GASKET	1
?	XA1986	CONTAINER ASSEMBLY (90 LB.)	1
?	BF5442	PLUG, PIPE (VENT)	2
?	BF5443	PLUG, PIPE (FILL)	1
?	BF5435	TUBE, EXTENSION	1
?	BF5425	ELBOW	1
?	BF5085	CAPSCREW	2
?	BF5084	LOCKWASHER	6
?	BF5423	CAPSCREW	4
?	BF5424	BRACKET	2
?	BF5436	NUT	4
?	BF5450	GASKET	1
?	BF5447	SCREW	4
?	BF5086	NUT	4
?	BF5449	ELBOW	1
?	BF5422	COVER	1
?	XA1988	GASKET	1
?	XA1985	PIPE, VENT	1
?	LA1187	VALVE, CHECK (SEE INDEX)	1	60398
?	BF5445	UNION	1
?	BF5082	NIPPLE	1
?	LA0912	VALVE, VENT (SEE INDEX)	1	60397
?	LA0605	UNLOADER, SAFETY	1
?	BF2446	ELBOW	1
?	BF5426	HOSE	1
?	XA1983	HOSE	1

Komatsu AFE59-FK 930E-4 S/N A31674 - A31676, A31685, A31687 & A31689 JWANENG parts catalog PDF

LUBE PUMP/CONTAINER ASSEMBLY PC2373 (61273) in AFE59-FK 930E-4 S/N A31674 - A31676, A31685, A31687 & A31689 JWANENG. Diagram image and parts list.
