AFE59-CY 930E-4 S/N A30990 & A30991 HYCROFT

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	XA4136	FLAT WASHER - 5/8" (HARDENED)	-1
?	XA4217	CAPSCREW - 5/8" - 11NC X 2"	-1
?	GE0129	FRAME, HEAD	1
?	VE5185	FLAT WASHER - 1/2"	8
?	VE4518	CAPSCREW - 1/2" - 13NC X 1 1/2"	4
?	GE0122	WEIGHT, BALANCING	-1
?	XA4262	ROTOR ASSEMBLY	1
?	GE0130	HOUSING, BEARING	1
?	GE0133	FLINGER	1
?	GE0134	COLLAR	1
?	GE0438	BEARING	1
?	XA4261	COLLAR	1
?	VS7492	SEALER - 5 OZ	-1
?	VE6232	CAPSCREW - 1/2" - 13NC X 3 1/4"	1
?	XA4260	CAP, BEARING	1
?	BF1660	SEAL, LIP	1
?	GE0437	SHAFT	1
?	GE0395	CAP, BEARING	1

Komatsu AFE59-CY 930E-4 S/N A30990 & A30991 HYCROFT parts catalog PDF

MOTOR ASSEMBLY - WHEEL 2/2 XA4259 (64255) in AFE59-CY 930E-4 S/N A30990 & A30991 HYCROFT. Diagram image and parts list.
