AFE59-GY 930E-4 S/N A32045 - A32046 & A32058 - A32061 VALE CARAJAS

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	WA1731	O-RING	3
?	WA1733	O-RING	1
?	HA7993	HOSE	1
?	HA7876	HOSE	1
?	PC1341	BRACKET	1
?	MM0583	CAPSCREW - M6 X 1.00 X 25	4
?	MM0459	FLAT WASHER - M6	4
?	WB1304	CLAMP, CUSHIONED - 9/16"	6
?	MM0461	FLAT WASHER - M10	11
?	MM0471	LOCKWASHER - M10	11
?	MM0178	NUT - M10 X 1.50	11
?	58F-07-00000	HOSE	1
?	WB1027	O-RING	3
?	58B-07-20000	ADAPTER	1
?	HA8065	HOSE	1
?	20D-09-11130	CLAMP	2
?	PC1830	ACCUMULATOR	1
?	XA4444	CAP, DUST (LOW SIDE SERVICE PORT)	1
?	XA4445	CAP, DUST (1/4" SWITCH PORT)	1
?	WB3093	CLAMP, CUSHIONED - 1"	7
?	TY8375	SPACER	7
?	08193-21012	CLIP	1
?	PC1804	SWITCH, TRINARY	1
?	PC2268	RECEIVER DRIER	1
?	DC3584	LOCKWASHER - 1/4"	1
?	TD1809	CAPSCREW - 1/4" - 20NC X 3/4"	1

Komatsu AFE59-GY 930E-4 S/N A32045 - A32046 & A32058 - A32061 VALE CARAJAS parts catalog PDF

AIR CONDITIONING PIPING (61986) in AFE59-GY 930E-4 S/N A32045 - A32046 & A32058 - A32061 VALE CARAJAS. Diagram image and parts list.
