REAR BRAKE ASSEMBLY 58F-33-40020 | AFE59-GN 930E-4 S/N A31993 CASSERONES

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

AFE59-GN 930E-4 S/N A31993 CASSERONES

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	EJ6749	PISTON AND HOUSING ASSEMBLY	1
?	EJ6748	HOUSING, PISTON	1
?	58F-33-40000	SEAL (4)	1
?	58F-33-40010	SEAL (4)	1
?	EG4953	PISTON	1
?	PB8864	SPRING	12
?	ED3327	GUIDE, SPRING	12
?	VL1222	CAPSCREW - 1/2" - 13NC X 5"	12
?	VM0315	PLUG (4)	3
?	WA1589	CAPSCREW - 7/8" - 9NC X 3" (12 PT)	102
?	WA5659	FLAT WASHER - SPECIAL (HARDENED)	102
?	VM0317	PLUG (4)	1
?	ED3339	GEAR, RING	1
?	EH7197	SEAL, O-RING (4)	2
?	ED3343	GEAR, INNER	1
?	EM8367	DAMPER (1)	2
?	EM8365	DISC, SEPARATOR (1)	9
?	EM8366	DISC, FRICTION (1)	10
?	58F-32-40040	PLATE, BACK	1
?	PC0651	SEAL ASSEMBLY (4)	1
?	BF4837	SEAL, TORIC	2
?	BF4116	RING, SEAL	2
?	BF4117	TOOL, INSTALLATION (2)	1
?	PC1431	SEAL, OIL (4)	1
?	58F-32-40030	CARRIER, SEAL	1
?	58F-32-40051	BRACKET, MOUNTING	6
?	D2930	CAPSCREW, SOCKET HEAD - 1/2" - 13NC X 3/4" (3)	6
?	C1612	CAPSCREW - 1/2" - 13NC X 1"	12
?	WA0360	FLAT WASHER - 1/2" (HARDENED)	12
?	EH7195	SEAL, O-RING (4)	1
?	58F-33-40050	ADAPTER, HUB	1
?	VN9065	CAPSCREW - 1/2" - 13NC X 2"	12
?	C1540	LOCKWASHER - 1/2" (4)	12
?	ED3755	SHIM - .020	54
?	ED3756	SHIM - .010	6
?	WA5660	CAPSCREW - 1 1/4" - 12NF X 7 1/2" (12 PT)	32
?	TY2149	FLAT WASHER (HARDENED)	32
?	58F-BK-AK100	NOTE: (1) INCLUDED IN 58F-BK-AK100 BRAKE DISC KIT.	-1
?		(2) NOT INCLUDED IN SEAL ASSEMBLY.	-1
?		(3) USED FOR ASSEMBLY AND STORAGE ONLY.	-1
?		REMOVE WHEN INSTALLED ON THE TRUCK.	-1
?	58F-BK-AK081	(4) INCLUDED IN 58F-BK-AK081 REAR BRAKE SEAL KIT.	-1
