AFE59-GH 930E-4 S/N A31966 - A31967 PENASQUITO

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	XA4237	COIL - 74 VDC	1
?	GE1836	KIT, CONTACTOR TIP	1
?	GE1072	ARC CHUTE	1
?	XA4239	COIL - 24 VDC	1
?	58E-43-00220	BRACKET, SUPPORT	1
?	58E-43-00230	INTERLOCK, MECHANICAL	1
?	58E-43-00240	LATCH SPRING, ARC CHUTE	1
?	58E-43-00250	LEVER	1
?	58E-43-00260	HOLDER, IRON	1
?	58E-43-00270	CAPSCREW , SOCKET HEAD - 5/16" - 18NC X 1 1/2"	1
?	58E-43-00280	TERMINAL, PIVOT	1
?	58E-43-00290	SPRING, LEAF	1
?	58E-43-00300	CAPSCREW, SOCKET HEAD - 5/16" - 18NC X 1 1/4"	1
?	58E-43-00310	PLATE, POLE	2
?	58E-43-00330	CORE, MAGNET	1
?	58E-43-00340	SHEET, INSULATING	1
?	58E-43-00350	SPACER, INSULATING	1
?	58E-43-00360	CAPSCREW - 5/16" - 18NC X 4 1/2"	1
?	58E-43-00370	SCREW, FLATHEAD - 3/8" - 16NC X 1"	1
?	58E-43-00380	LOCKWASHER, COUNTERSUNK	1
?	58E-43-00390	YOKE	1
?	58E-43-00320	COIL KIT, BLOWOUT	1

Komatsu AFE59-GH 930E-4 S/N A31966 - A31967 PENASQUITO parts catalog PDF

CONTACTOR ASSEMBLY - RP GE1843 (64401) in AFE59-GH 930E-4 S/N A31966 - A31967 PENASQUITO. Diagram image and parts list.
