AFE77-D 830E-5 S/N A50007 & A50018 UNITED TACONITE

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	WB0584	FITTING, STRAIGHT	1
?	58E-60-02260	HOSE	1
?	WB0375	FITTING, ELBOW - 90 DEG	1
?	WB0557	FITTING, TEE	1
?	VH6718	CLAMP, SPLIT FLANGE - 2 1/2"	2
?	WA0232	O-RING	1
?	C1615	CAPSCREW - 1/2" - 13NC X 1 3/4"	8
?	C1540	LOCKWASHER - 1/2"	20
?	TF3231	CLAMP, SPLIT FLANGE - 2"	6
?	WA0187	O-RING	3
?	C1614	CAPSCREW - 1/2" - 13NC X 1 1/2"	8
?	WB0508	FITTING, ELBOW - 90 DEG	2
?	EL3483	TUBE	1
?	C1619	CAPSCREW - 1/2" - 13NC X 2 3/4"	4
?	WB0547	FITTING, ELBOW - 45 DEG	2
?	WA3568	FITTING, TUBE	2
?	PB4685	COUPLING, HYDRAULIC	2
?	TA2968	PLUG, DUST	2
?	PB6770	COUPLING, MALE QUICK DISCONNECT	5
?	VM0313	PLUG	1
?	WA0360	FLAT WASHER, HARDENED - 1/2"	8
?	58B-60-50000	ANGLE	2
?	WB0988	CLAMP, HEAVY DUTY	2
?	C1523	NUT - 1/2" - 13NC	4

Komatsu AFE77-D 830E-5 S/N A50007 & A50018 UNITED TACONITE parts catalog PDF

VALVE/PUMP MODULE PIPING 2/3 (64683) in AFE77-D 830E-5 S/N A50007 & A50018 UNITED TACONITE. Diagram image and parts list.
