AFE77-D 830E-5 S/N A50007 & A50018 UNITED TACONITE

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	VN9351	RING, RETAINING (1)	4
?	PC2053	BEARING, SPHERICAL (1)	2
?		REAR SUSPENSION ASSEMBLY	1
?	EL7931	HOUSING	1
?	VM0313	PLUG	4
?	TY8879	PLUG, VENT	1
?	WA2892	PLATE, DANGER	2
?	R1073	DRIVE SCREW - #6 X 3/16"	8
?	TZ9093	PLUG	1
?	PB2194	CHARGING VALVE ASSEMBLY (2)	1
?	TD7179	CORE, VALVE	1
?	TR9993	CAP, VALVE	1
?	TF1144	O-RING, HOUSING	1
?	WA0052	O-RING, VALVE STEM	1
?	VD5076	GASKET, FLAT (2)	1
?	TZ8637	PLUG, SENSOR	1
?	PC2585	BEARING, ROD (3)	1
?	WA0179	O-RING (2)/(3)	1
?	EL7129	RING, BACKUP (2)/(3)	1
?	EL6745	RETAINER, BEARING	1
?	PC0629	SEAL, BUFFER (2)/(3)	1
?	PC0628	SEAL, DOUBLE LIP (2)/(3)	1
?	PC0630	SEAL, WIPER (2)/(3)	1
?	VN9140	CAPSCREW - 3/4" - 10NC X 4"	24
?	WA0362	FLAT WASHER - 3/4"	24
?	EL7935	PISTON	1
?	PC2584	BEARING, PISTON (3)	1
?		NOTE: NS = NOT SHOWN	-1
?	AK4065	SUSPENSION OIL MIXTURE - COLD WEATHER - 5 GAL	-1
?	AK4066	SUSPENSION OIL MIXTURE - COLD WEATHER - 55 GAL	-1
?	58E-MP-AK060	NOTE: (1) INCLUDED IN 58E-MP-AK060 PIN KIT.	-1
?		SERVICES ONE PIN.	-1
?	58E-RS-AK011	(2) INCLUDED IN 58E-RS-AK011 REAR SUSPENSION KIT.	-1
?	58C-00-00150	(3) INCLUDED IN 58C-00-00150 REAR SUSPENSION SEAL KIT.	-1
?		(QUANTITIES SHOWN ARE FOR ONE SIDE ONLY.)	-1

Komatsu AFE77-D 830E-5 S/N A50007 & A50018 UNITED TACONITE parts catalog PDF

REAR SUSPENSION W/BEARINGS (CW) EM8839 (43999) in AFE77-D 830E-5 S/N A50007 & A50018 UNITED TACONITE. Diagram image and parts list.
