RH STEPS & PLATFORM | AFE75-B 980E-5 S/N A50006 - A50007 TECK

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

AFE75-B 980E-5 S/N A50006 - A50007 TECK

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	58B-54-04790	PLATFORM, RH	1
?	XB3027	HANDRAIL	1
?	58B-54-04800	HANDRAIL	1
?	MM0706	FLAT WASHER, HARDENED - M16	4
?	58E-09-00400	FLAT WASHER, HARDENED - M16	2
?	58F-09-00400	CAPSCREW - M16 X 2.00 X 25	2
?	MM0620	CAPSCREW - M12 X 1.75 X 40	9
?	MM0714	FLAT WASHER, HARDENED - M12	18
?	MM0472	LOCKWASHER - M12	11
?	MM0179	NUT - M12 X 1.75	10
?	EL6441	HANDRAIL	1
?	EL6443	HANDRAIL	1
?	MM0471	LOCKWASHER - M10	4
?	MM0606	CAPSCREW - M10 X 1.50 X 30	8
?	MM0713	FLAT WASHER, HARDENED - M10	4
?	EM9230	PLATE, COVER	1
?	58F-09-00410	LOCKNUT - M12 X 1.75	4
?	MM0624	CAPSCREW - M12 X 1.75 X 70	4
?	MM0720	NUT - M12 X 1.75	6
?	MM0618	CAPSCREW - M12 X 1.75 X 30	2
?	MM0462	FLAT WASHER - M12	12
?	EL6439	STRAP, RUBBER	2
?	EL6436	STRAP, RUBBER	2
?	EL0827	TREAD	2
?	58B-80-02230	MOUNT, LADDER	1
?	MM0623	CAPSCREW - M12 X 1.75 X 60	12
?	MM0619	CAPSCREW - M12 X 1.75 X 35	11
?	58F-09-00460	CAPSCREW - M16 X 2.00 X 45	4
