REAR AXLE INSTALLATION | AFE75-B 980E-5 S/N A50006 - A50007 TECK

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

AFE75-B 980E-5 S/N A50006 - A50007 TECK

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	58B-22-00820	HOUSING, AXLE	1
?	TX8110	SLEEVE (2)	2
?	58B-50-00130	CAPSCREW - 1 3/8" - 6NC X 4"	28
?	EK5634	FLAT WASHER - 1 3/8"	28
?	58B-22-00530	PIVOT EYE ASSEMBLY (3)	1
?	58B-22-00560	EYE, PIVOT	1
?	58B-22-00550	BEARING, SPHERICAL (1)	1
?	58B-22-00540	CARRIER, BEARING	-1
?	VN9953	LOCKNUT - 7/8" - 9NC (1)	14
?	58B-22-00520	RETAINER, BEARING (1)	2
?	EH7811	PIN, PANHARD ROD (2)	2
?	XB0690	PIN, DRIVE PIVOT (1)	1
?	VN9952	LOCKNUT - 5/8" - 11NC (2)	2
?	WB3026	CAPSCREW - 7/8" - 9NC X 6 3/4" (1)	14
?	EK1746	RETAINER, PIN (1)	1
?	WB1059	CAPSCREW, 12 PT - 1 1/4" - 7NC X 4 1/2" (1)	5
?	WA0361	FLAT WASHER, HARDENED - 5/8" (2)	2
?	VN9087	CAPSCREW - 5/8" - 11NC X 2 1/2" (1)	3
?	C1541	LOCKWASHER - 5/8" (1)	3
?	EM8109	SHOULDER BOLT - 5/8" - 11NC X 7.16" (FRAME END) (2)	1
?	EM8121	SHOULDER BOLT - 5/8" - 11NC X 7.01" (AXLE END) (2)	1
?	58F-50-00130	SPACER (2)	4
?	EH7812	ANTI-SWAY BAR W/BEARINGS	1
?	EH7813	BAR, ANTI-SWAY	1
?	VN9351	RING, RETAINING (2)	4
?	PB9622	BEARING, SPHERICAL (2)	2
?	D1423	PLUG, PIPE	2
?	58B-22-00510	SPACER	2
?	58B-MP-AK160	NOTE: (1) INCLUDED IN 58B-MP-AK160 NOSE CONE PIN KIT.	-1
?	58B-MP-AK150	(2) INCLUDED IN 58B-MP-AK150 ANTI-SWAY BAR KIT.	-1
?		(3) NOT SERVICED AS AN ASSEMBLY. ORDER	-1
?		INDIVIDUAL COMPONENT PARTS.	-1
