AFE73-J 980E-4 S/N A40124 & A40131 - A40133 EPSA

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	EM1328	LADDER, ACCESS - LH SIDE	1
?	EM1331	LADDER, ACCESS - RH SIDE	1
?	VN9952	LOCKNUT - 5/8" - 11NC	4
?	WA4863	FLAT WASHER - 5/8"	8
?	TV1748	CAPSCREW - 5/8" - 11NC X 1 1/2"	4
?	XB3387	HANDRAIL - LH SIDE	1
?	XB3396	HANDRAIL - RH SIDE	1
?	EM4706	HANDRAIL - LH SIDE	1
?	EM4704	HANDRAIL - RH SIDE	1
?	MM0619	CAPSCREW - M12 X 1.75 X 35	12
?	MM0694	LOCKNUT - M12 X 1.75	12
?	MM0462	FLAT WASHER - M12	28
?	MM0618	CAPSCREW - M12 X 1.75 X 30	4
?	MM0472	LOCKWASHER - M12	16
?	MM0714	FLAT WASHER - M12 (HARDENED)	24
?	MM0620	CAPSCREW - M12 X 1.75 X 40	12
?	MM0179	NUT - M12 X 1.75	12
?	EM5084	STEPS, ENGINE EGRESS - LH SIDE	1
?	EM5085	STEPS, ENGINE EGRESS - RH SIDE	1
?	58F-80-40320	PLATFORM, ENGINE - LH SIDE	1
?	58F-80-40310	PLATFORM, ENGINE - RH SIDE	1
?	MM0029	CAPSCREW - M16 X 2.00 X 30	8
?	MM0464	FLAT WASHER - M16	8

Komatsu AFE73-J 980E-4 S/N A40124 & A40131 - A40133 EPSA parts catalog PDF

ENGINE ACCESS LADDERS & PLATFORMS - OPTIONAL (61932) in AFE73-J 980E-4 S/N A40124 & A40131 - A40133 EPSA. Diagram image and parts list.
