AFE73-B 980E-4 S/N A40031 - A40032 ANTAMINA

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	58B-54-01021	HANDRAIL, RETARDING GRID - REAR	1
?	58B-54-01051	HANDRAIL, RETARDING GRID - FRONT	1
?	EL9093	BRACKET	4
?	58F-54-03920	BRACKET	6
?	C1616	CAPSCREW - 1/2" - 13NC X 2"	24
?	TR5445	LOCKWASHER - 1/2"	24
?	TR6008	FLAT WASHER - 1/2"	24
?	MM0619	CAPSCREW - M12 X 1.75 X 35	16
?	MM0714	FLAT WASHER - M12 (HARDENED)	38
?	MM0472	LOCKWASHER - M12	21
?	MM0179	NUT - M12 X 1.75	19
?	58E-54-13870	BRACKET	2
?	58B-54-01240	TUBE	1
?	58B-54-01270	TUBE	1
?	MM0620	CAPSCREW - M12 X 1.75 X 40	3
?	MM0618	CAPSCREW - M12 X 1.75 X 30	2
?	58B-54-01200	PLATE, BENT	1
?	58B-54-01210	PLATE, BENT	1

Komatsu AFE73-B 980E-4 S/N A40031 - A40032 ANTAMINA parts catalog PDF

HANDRAILS - RETARDING GRID (63000) in AFE73-B 980E-4 S/N A40031 - A40032 ANTAMINA. Diagram image and parts list.
