AFE73-B 980E-4 S/N A40031 - A40032 ANTAMINA

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	TR4731	CAPSCREW - 5/16" - 18NC X 1"	8
?	VE4696	LOCKWASHER - 5/16"	8
?	VE4343	FLAT WASHER - 5/16"	8
?	XA3594	BUS BAR	1
?	XA3596	BUS BAR	1
?	VE4698	NUT - 1/2" - 13NC	20
?	VE4699	LOCKWASHER - 1/2"	20
?	VE4519	FLAT WASHER - 1/2" (NARROW)	8
?	VE3030	FLAT WASHER - 1 1/4" OD	20
?	VE5062	CAPSCREW - 1/2" - 13NC X 2 3/4"	8
?	PB3348	INSULATOR	14
?	GE0581	STUD	2
?	58F-43-00420	CHANNEL ASSEMBLY	2
?	XA3797	BUS BAR	1
?	GE0756	LINK SENSOR, AC-DC	1
?	XA3599	BASE ASSEMBLY	1
?	XA5287	CAPSCREW - 1/4" - 20NC X 7/8"	4
?	XA5003	LOCKWASHER - 1/4"	8
?	58D-98-02180	FLAT WASHER - 1/4"	8
?	GE1394	BUS BAR, INSULATED	1
?	GE1400	BUS BAR	1
?	GE1403	BUS BAR	1
?	GE1404	BUS BAR, INSULATED	1
?	XA3143	STUD	12
?	GE1379	PLUG	8
?	XA3722	BRACKET, MOUNTING	6
?	XA5281	BRACKET, MOUNTING	6
?	XA4286	CAPSCREW, SOCKET HEAD - 3/8" - 16NC X 1"	24
?	VE4687	LOCKWASHER - 3/8"	24
?	VE4515	FLAT WASHER - 3/8"	24
?	GE0170	SENSOR, AC-DC	12
?	VE4602	NUT - #10 - 32NF	48
?	VE4601	LOCKWASHER - #10	48
?	VE4655	FLAT WASHER - #10	48

Komatsu AFE73-B 980E-4 S/N A40031 - A40032 ANTAMINA parts catalog PDF

CONTROL CABINET - HIGH VOLTAGE 5/6 58B-43-00700 (64450) in AFE73-B 980E-4 S/N A40031 - A40032 ANTAMINA. Diagram image and parts list.
