AFE73-B 980E-4 S/N A40031 - A40032 ANTAMINA

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	58B-32-00380	PISTON ASSEMBLY (1)	1
?	58B-32-00090	HOUSING, PISTON	1
?	58B-33-00180	SEAL ASSEMBLY (2)	1
?	58B-33-00170	SEAL ASSEMBLY (2)	1
?	EJ5849	PISTON	1
?	EJ6986	SPRING, COMPRESSION	12
?	EJ6985	GUIDE, SPRING	12
?	VN9149	CAPSCREW - 1/2" - 13NC X 4 1/2"	12
?	VM0317	PLUG (2)	1
?	VM0315	PLUG (2)	1
?	PC1427	DOWEL, SPRING (2)	2
?	VG9098	O-RING (2)	2
?	EH7197	SEAL, O-RING (2)	2
?	58B-32-00080	GEAR, OUTER	1
?	EK2738	GEAR, INNER	1
?	EM8371	DAMPER (3)	2
?	EM8365	PLATE, SEPARATOR (3)	10
?	EM8366	DISC, FRICTION (3)	11
?	WA4780	PLUG, O-RING	1
?	58B-32-00070	PLATE, BACK	1
?	WA4174	FLAT WASHER - 1"	90
?	WA0908	CAPSCREW - 1" - 8NC X 3" (12 PT)	90
?	58F-22-00850	VENT, BREATHER	1
?	H8402	PLUG - 3/8"	1
?		NOTE: (1) NOT SERVICED AS AN ASSEMBLY.	-1
?	58B-BK-AK050	(2) INCLUDED IN 58B-BK-AK050 FRONT BRAKE SEAL KIT.	-1
?	58B-00-00390	(3) INCLUDED IN 58B-00-00390 BRAKE DISC KIT.	-1

Komatsu AFE73-B 980E-4 S/N A40031 - A40032 ANTAMINA parts catalog PDF

FRONT BRAKE ASSEMBLY (WET DISC) 58B-32-00021 (62956) in AFE73-B 980E-4 S/N A40031 - A40032 ANTAMINA. Diagram image and parts list.
