AFE69-F 730E-8 S/N A40018 - A40034 NATALKA

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity	Reference
?	58F-03-40150	VALVE ASSEMBLY (SEE INDEX)	1	45323
?	HA7887	HOSE	2
?	WB0261	FITTING, ELBOW - 90 DEG	2
?	58D-60-80350	HOSE	1
?	58D-60-80340	HOSE	1
?	WB0384	FITTING, TEE	1
?	WB0381	FITTING, TEE	1
?	MM0030	CAPSCREW - M8 X 1.25 X 30	4
?	MM0460	FLAT WASHER - M8	4
?	MM0470	LOCKWASHER - M8	4
?	WB1300	CLAMP, CUSHIONED - 5/8"	4
?	WB3855	CLAMP, CUSHIONED - 13/16"	5
?	WB0501	FITTING, ELBOW - 90 DEG	1
?	TG5720	CAPSCREW - 3/8"-16 X 1.00 G5	2
?	WA4726	FLAT WASHER - 3/8" (HARDENED)	2
?	WB3092	CLAMP, CUSHIONED - 7/8"	14
?	MM0471	LOCKWASHER - M10	7
?	MM0461	FLAT WASHER - M10	7
?	MM0178	NUT - M10 X 1.50	7
?	58D-09-00010	FITTING, TEE	1

Komatsu AFE69-F 730E-8 S/N A40018 - A40034 NATALKA parts catalog PDF

RADIATOR SHUTTER INSTALLATION 2/2 (45360) in AFE69-F 730E-8 S/N A40018 - A40034 NATALKA. Diagram image and parts list.
