AFE69-F 730E-8 S/N A40018 - A40034 NATALKA

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	VS6823	RESISTOR - 50W, 10 OHM	2
?	VE5976	SCREW - #6 - 40NF X 7/8"	1
?	VE5756	FLAT WASHER - #6	4
?	VE5755	LOCKWASHER - #6	4
?	VE5959	NUT	4
?	VE4608	CAPSCREW - #10 - 32NF X 3/4"	10
?	VE4600	FLAT WASHER - #10	-1
?	VE4601	LOCKWASHER - #10	-1
?	VE4602	NUT - #10 - 32NF	-1
?	VE0687	MODULE	1
?	VE5974	SCREW - #10 - 32NF X 1 1/8"	5
?	VE5972	SCREW, CAPTIVE	2
?	58B-43-00600	WASHER, RETAINING	2
?	VP9597	SCREW - #6 - 40NF X 5/8"	3
?	VE5133	CLAMP, CABLE	2
?	58B-43-00620	MODULE	2
?	VE4917	CLAMP, CABLE	1
?	58B-43-00510	RESISTOR	2
?	VE4921	CAPSCREW - #10 - 32NF X 1"	7
?	58B-43-00500	BASE	1
?	PB3606	SPACER	2
?	VE7272	SEALANT	-1
?	58B-43-00590	BRACKET	1
?	VE5971	WASHER	4
?	58B-43-00630	SPACER	4
?	VE4916	CAPSCREW - #10 - 32NF X 1/2"	4
?	VE5156	CAPSCREW - #10 - 32NF X 7/8"	4
?	58B-43-00580	BRACKET	1
?	VE4610	SCREW - #10 - 32NF X 5/8"	4
?	GE0236	WASHER	4
?	VE4597	WASHER - 1/2"	8
?	VE5975	SCREW	2
?	VE4385	CAP NUT	4

Komatsu AFE69-F 730E-8 S/N A40018 - A40034 NATALKA parts catalog PDF

AFSE PANEL COVER ASSEMBLY 1/2 58B-43-00480 (45334) in AFE69-F 730E-8 S/N A40018 - A40034 NATALKA. Diagram image and parts list.
