PB8658
|
SCREW - M6 X 1.00 X 30 |
10 |
|
|
|
|
? |
WB2490
|
DECAL, WARNING (KEY SWITCH) |
1 |
|
|
|
|
? |
WB3295
|
DECAL, SHIFT SELECTOR |
1 |
|
|
|
|
? |
DC9822
|
DRIVE SCREW |
8 |
|
|
|
|
? |
XB0405
|
DASH MODULE, LOWER RH (SEE FIG 42684) |
1 |
|
42684 |
|
|
? |
EK8962
|
SEAL, LOWER MODULE |
2 |
|
|
|
|
? |
EL3495
|
DASH MODULE, UPPER RH (SEE FIG 60931) |
1 |
|
60931 |
|
|
? |
EK8961
|
SEAL, UPPER MODULE |
1 |
|
|
|
|
? |
EK7947
|
LOUVER, RECTANGULAR |
2 |
|
|
|
|
? |
EK7946
|
ADAPTER, HOSE |
2 |
|
|
|
|
? |
SM5145
|
TUBE (TO TOP LOUVERS) |
2 |
|
|
|
|
? |
WA4513
|
SCREW, SELF-TAPPING - #10 - 24NC X 1/2" |
4 |
|
|
|
|
? |
PC1927
|
PANEL, GAUGE (SEE FIG 61325) |
1 |
|
61325 |
|
|
? |
PC1938
|
HARNESS, MAIN GAUGE PANEL |
1 |
|
|
|
|
? |
PC1939
|
HARNESS, WARNING PANEL |
1 |
|
|
|
|
? |
PC1929
|
PANEL, STATUS |
1 |
|
|
|
|
? |
SM2466
|
SCREW - #10 - 24NC X 1/2" |
4 |
|
|
|
|
? |
EL3494
|
DASH MODULE, LOWER LH (SEE FIG 61324) |
1 |
|
61324 |
|
|
? |
TX7829
|
SEAL, STEERING COLUMN |
1 |
|
|
|
|
? |
SM2646
|
PLATE, SEAL RETAINER - LH |
1 |
|
|
|
|
? |
SM2648
|
PLATE, SEAL RETAINER - RH |
1 |
|
|
|
|
? |
EL5675
|
DASH PANEL, MOLDED |
1 |
|
|
|
|
? |
PB9829
|
SCREW - M6 X 1.00 X 16 |
10 |
|
|
|
|
? |
|
NOTE: NS = NOT SHOWN |
-1 |
|
|
|
|
? |
SM2783
|
HOSE, AIR (BEHIND INSTRUMENT PANEL) |
2 |
|
|
|
|
? |
CC6103
|
CLAMP, WORM DRIVE (FOR AIR HOSES) |
4 |
|
|
