AIR CLEANER PIPING & INSTALLATION | AFE47-DH 730E S/N A30375 ALCOA

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

AFE47-DH 730E S/N A30375 ALCOA

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity	Reference
?	EF5719	PLENUM - R.H.	1
?	EG0738	PLENUM - L.H.	1
?	PB2433	CLEANER, AIR (SEE INDEX)	2	35081
?	TB1406	GUARD, RAIN - FRONT	2
?	EB0983	GUARD, RAIN - R.H.	1
?	EB0984	GUARD, RAIN - L.H.	1
?	TV1748	CAPSCREW - 5/8" - 11NC X 1 1/2"	33
?	TR9082	FLAT WASHER - 5/8"	33
?	VC1390	LOCKWASHER - 5/8"	33
?	VW7769	HOSE, HUMP	7
?	WA1083	CLAMP, T-BOLT	14
?	EF5720	TUBE - R.H.	1
?	EF5722	TUBE - L.H.	1
?	C5768	PLUG, PIPE	2
?	VW7036	HOSE, FLEX	1
?	WB0928	CLAMP, T-BOLT	2
?	WA0471	CAPSCREW - 1/2" - 13NC X 2 1/4"	6
?	WA4728	FLAT WASHER - 1/2" (HARDENED)	12
?	DF3500	LOCKNUT - 1/2" - 13NC	6
?	PC1247	END, ROD (FEMALE SPECIAL)	6
?	TL8151	JAM NUT - 1/2" - 20NF	6
?	EK2341	ROD, THREADED - 1/2" X 7.28"	2
?	EK3399	ROD, THREADED - 1/2" X 19.69"	1
?	EK2834	CLAMP	3
