AFE75-M 980E-5 S/N A50044 - A50046, A50048 COPPER MOUNTAIN

? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity	Reference
?	58B-50-10000	FRONT SUSPENSION ASSEMBLY - CW (SEE INDEX)	1	69775
?	VN9193	CAPSCREW - 1 1/2" - 6NC X 6 1/2" (1)	6
?	WA0368	FLAT WASHER, HARDENED - 1 1/2" (1)	12
?	WA0404	NUT - 1 1/2" - 6NC (1)	6
?	EL0932	FLAT WASHER - 2" (1)	12
?	EL0945	CAPSCREW - 2" - 4.5NC X 15" (1)	8
?	WA0406	NUT - 2" - 5NC (1)	4
?	EL7294	SPACER (1)	4
?	58B-50-00910	KEY, SHEAR	1
?		NOTE: NS = NOT SHOWN	-1
?	WA3925	DECAL, HYDRAIR II	1
?	58B-MH-AK150	NOTE: (1) INCLUDED IN 58B-MH-AK150 FRONT SUSPENSION	-1
?		MOUNTING KIT.	-1
?		(QUANTITIES SHOWN ARE FOR ONE SIDE ONLY.)	-1

Komatsu AFE75-M 980E-5 S/N A50044 - A50046, A50048 COPPER MOUNTAIN parts catalog PDF

FRONT SUSPENSION INSTALLATION - FRAME (63455) in AFE75-M 980E-5 S/N A50044 - A50046, A50048 COPPER MOUNTAIN. Diagram image and parts list.
