HYDR.-CYLINDER | PC3000-1 S/N 06190 | Komatsu parts book catalogue

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

PC3000-1 S/N 06190

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	915 827 40	Hydraulic cylinder	1
?		Cylinder barrel These parts are not sold separately	1
?	430 867 40	Flanged bush	2
?	907 019 40	Seal ring	2
?	004 860 98	Grease nipple	4
?	792 143 73	Piston rod assy. incl. fig-nos. 04,05,07,08	1
?		Piston rod These parts are not sold separately	1
?	882 157 40	Flanged bush	2
?	909 563 40	Sealing flange assy. incl. fig-nos. 10-12 (finish work after bush is installed)	1
?		Flanged bush These parts are not sold separately	1
?	897 707 40	Bearing bush	1
?	342 688 99	Circlip	1
?	460 338 40	Piston	1
?	438 984 40	Groove nut	1
?	909 342 40	Cover ring	1
?	202 702 40	Seal ring	1
?	202 703 40	O-ring	1
?	255 760 40	Piston guide ring	4
?	324 952 40	Piston guide strap	2
?	440 400 40	Rod seal	1
?	906 501 40	Scraper	1
?	007 632 98	O-ring	1
?	226 431 40	Support ring	1
?	000 219 98	O-ring	1
?	256 724 40	Support ring	2
?	354 389 99	Feather key	1
?	320 156 99	Bolt	20
?	319 288 99	Bolt	8
?	501 025 98	Threaded pin	1
?	506 581 98	Plug	1
?	356 209 40	Flange seal	1
?	906 707 40	Support ring	1
?	697 677 73	Seal kit - piston consist. of fig-nos: 17-20,25,26	1
?	770 460 73	Seal kit - piston rod consist. of fig-nos: 21-24, 34	1
