HYDR.-CYLINDER | PC3000-6 S/N 06271 | Komatsu parts book catalogue

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

PC3000-6 S/N 06271

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	924 900 40	Hydraulic cylinder (standard)	1
?	934 615 40	Hydraulic cylinder (cold weather design)	1
?		Cylinder barrel	1
?	907 022 40	Seal ring	4
?	004 860 98	Grease nipple	3
?	792 429 73	Piston rod assy. incl. fig-nos. 05,06,08,09	1
?		Piston rod	1
?	627 572 40	Freeze-in bushing	1
?	926 859 40	Sealing flange incl. fig-nos. 11,12+17	1
?		Flanged bush	1
?	926 899 40	Bearing bush (no field repair item)	1
?	659 097 40	Piston assy. incl. fig-nos. 14+15	1
?		Piston	1
?	445 393 40	Liner (no field repair item)	1
?	947 190 40	Groove nut	1
?	342 698 99	Circlip	1
?	269 475 40	Sealing element (standard)	1
?	896 587 40	Sealing element (cold weather design)	1
?	256 248 40	O-ring (standard)	1
?	515 788 98	O-ring (cold weather design)	1
?	256 245 40	Piston guide ring	5
?	269 785 40	Piston guide strap	2
?	440 675 40	O-ring (standard)	1
?	510 414 98	O-ring (cold weather design)	1
?	655 589 40	Support ring	2
?	517 018 98	O-ring (standard)	1
?	502 670 98	O-ring (cold weather design)	1
?	907 666 40	Support ring	1
?	318 798 99	Bolt (standard)	18
?	511 722 98	Screw (cold weather design)	18
?	354 389 99	Feather key	1
?	947 188 40	Threaded pin	1
?	7075120810	Buffer ring	1
?	7075120080	Rod seal (standard)	1
?	7075120730	Rod seal (cold weather design)	1
?	5816392670	Dust seal	1
?	517 563 98	Circlip	1
?	767 498 73	Seal kit piston consist. of fig nos: 19-24 (standard)	1
?	793 480 73	Seal kit piston rod consist. of fig.-nos: 26,27,33-35 (standard)	1
?	794 967 73	Seal kit piston consist. of fig nos: 19-24 (cold weather design)	1
?	794 968 73	Seal kit piston rod consist. of fig.-nos: 26,27,33-35 (cold weather design)	1
